Tractor · 2016Unverified

CaseIH Farmall 110U

Name: CaseIH Farmall 110U
Brand: CaseIH

CaseIH Farmall 110U — Farmall U Series · 98 hp. Reference specifications; pending source verification.

The CaseIH Farmall 110U is a tractor model with a rated power output of 98 hp, categorised as a mid-range figure for its class. This model was manufactured in 2016. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It has a listed operating weight of 4550 kg and is suited to operations on areas ranging from 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

98 hp

Max power

74.1 kW

Weight

4550 kg

Catalogue coverage

Variants represented

Richest spec table

75 rows

Recorded power

98 hp

Recorded weight

4550 kg

Transmissions

16-speed 4-speed power shift

Production years

2016-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Utility tractorReference

Four-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

FPT 3.4L 4-cyl dieselReference

Fuel tank165.0 LReference

Exhaust fluid (DEF)12.1 LReference

Engine79.8 kWReference

Drawbar (tested)53.4 kWReference

FPTReference

turbocharged aftercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke99 x 110 mmReference

EmissionsTier IVReference

Power79.8 kWReference

Fuel systemelectronic high-pressure common rail direct injectionReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Max power74.1 kWReference

Power at rated engine speed72.9 kWReference

Max power53.4 kWReference

Transmission

16-speed 4-speed power shiftReference

16-speedReference

32-speed creeperReference

Type4-speed power shiftReference

Gears16 forward and reverseReference

Four power shift gears in four ranges with shuttle.Reference

TransmissionAutoshiftReference

TypecreeperReference

Gears32 forward and reverseReference

PTO & Hydraulics

PTO (claimed)69.4 kWReference

PTO (tested)74.1 kWReference

Typeopen centerReference

Rear valves2 or 3Reference

Pump flow79.9 lpmReference

Rear TypeIIReference

Controlelectronic draft controlReference

Rear lift (at 24"/610mm)3995 kgReference

DrawbarCat. 2Reference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Power at rated PTO speed74.1 kWReference

Dimensions

Wheelbase237 cmReference

Weight4550 kgReference

Front tire14.9R24Reference

Rear tire460/85R34Reference

Standard tires (ag)Front: 14.9R24. Rear: 460/85R34Reference

Length419 cmReference

Width224 cmReference

Height (cab)271 cmReference

Flange rear axleReference

4550 kgReference

Ballasted6200 kgReference

Ballasted8000 kgReference

CaseIH Farmall 110U attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Battery volts12Reference

Attachment overview

CaseIH L103 loaderReference

CaseIH L103 MSL loaderReference

Test results

Diesel 16-speed 4WDFebruary 2016 - March 2016, Link: OCED Tractor Test 2977 fileReference

PTO performanceReference

Fuel use21.2 l/hourReference

Fuel use22.0 l/hourReference

Drawbar performanceReference

Gear 6L used for power test.Reference

Max pull4116 kgReference

Gear 4L used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
