Tractor · 2024Unverified
CaseIH Farmall 120M
CaseIH Farmall 120M — Farmall M Series · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Cab standard with air-conditioning.Reference
Engine
FPT 3.4L 4-cyl dieselReference
Engine89.5 kWReference
FPTReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsTier IVReference
Power89.5 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed partial power shiftReference
TransmissionActiveDrive 4Reference
Typepartial power shiftReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)74.6 kWReference
Controlelectronic draft controlReference
Rear lift3995 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
