Tractor · 2016Unverified
CaseIH Farmall 120U
CaseIH Farmall 120U — Farmall U Series · 104 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
104 hp
Max power
78.0 kW
Weight
4550 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Four-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
FPT 3.4L 4-cyl dieselReference
Fuel tank165.0 LReference
Exhaust fluid (DEF)12.1 LReference
Engine87.2 kWReference
Drawbar (tested)56.8 kWReference
FPTReference
turbocharged aftercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsTier IVReference
Power87.2 kWReference
Fuel systemelectronic high-pressure common rail direct injectionReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Max power78.0 kWReference
Power at rated engine speed77.2 kWReference
Max power56.8 kWReference
Transmission
16-speed 4-speed power shiftReference
16-speedReference
32-speed creeperReference
Type4-speed power shiftReference
Gears16 forward and reverseReference
Four power shift gears in four ranges with shuttle.Reference
TransmissionAutoshiftReference
TypecreeperReference
Gears32 forward and reverseReference
PTO & Hydraulics
PTO (claimed)74.6 kWReference
PTO (tested)78.0 kWReference
Typeopen centerReference
Rear valves2 or 3Reference
Pump flow79.9 lpmReference
Rear TypeIIReference
Controlelectronic draft controlReference
Rear lift (at 24"/610mm)3995 kgReference
DrawbarCat. 2Reference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed78.0 kWReference
Dimensions
Wheelbase237 cmReference
Weight4550 kgReference
Front tire14.9R24Reference
Rear tire460/85R34Reference
Standard tires (ag)Front: 14.9R24. Rear: 460/85R34Reference
Length419 cmReference
Width224 cmReference
Height (cab)271 cmReference
Flange rear axleReference
4550 kgReference
Ballasted6200 kgReference
Ballasted8000 kgReference
CaseIH Farmall 120U attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery volts12Reference
Attachment overview
CaseIH L103 loaderReference
CaseIH L103 MSL loaderReference
Test results
Diesel 16-speed 4WDFebruary 2016 - March 2016, Link: OCED Tractor Test 2972 fileReference
PTO performanceReference
Fuel use22.3 l/hourReference
Fuel use23.1 l/hourReference
Drawbar performanceReference
Gear 6L used for power test.Reference
Max pull4089 kgReference
Gear 4L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
