Search/Tractor/CaseIH/Farmall 25A

Tractor · 2024Unverified

CaseIH Farmall 25A

Name: CaseIH Farmall 25A
Brand: CaseIH

CaseIH Farmall 25A — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1119 kg

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Two-post folding ROPS.Reference

Variants

Workmaster 25similar New Holland modelReference

Engine

Mitsubishi 1.3L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine (gross)18.3 kWReference

MitsubishiReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 92 mmReference

EmissionsTier IVReference

Power (gross)18.3 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed sync shuttleReference

hydrostaticReference

Typesync shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

PTO (claimed)14.3 kWReference

Typeopen centerReference

Rear valves1Reference

Pump flow29.9 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)650 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM2000Reference

Dimensions

Wheelbase167 cmReference

Weight1119 kgReference

Length297 cmReference

Height (ROPS)224 cmReference

Height (Folded ROPS)173 cmReference
