Tractor · 2017Unverified

CaseIH Farmall 40A Series II

Name: CaseIH Farmall 40A Series II
Brand: CaseIH

CaseIH Farmall 40A Series II — Model year 2017-20252026-2027 · 34 hp. Reference specifications; pending source verification.

The CaseIH Farmall 40A Series II is a compact tractor rated at 34 hp. Manufactured from 2017 to 2027, it features a 3-cylinder turbocharged diesel liquid-cooled engine driving a four-wheel drive system with a hydrostatic transmission. The listed weight of the tractor is 1391 kg, and it is suited for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

34 hp

Weight

1391 kg

Catalogue coverage

Variants represented

Richest spec table

73 rows

Recorded power

34 hp

Recorded weight

1391 kg

Transmissions

12-speed mechanical shuttle

Production years

2017-2027

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Compact Utility tractorReference

Original price$21,817 (2021 gear )Reference

Original price$29,753 (2025 gear )Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Variants

Farmall 40AbasicReference

Farmall 40CpremiumReference

Workmaster 40similar New Holland modelReference

Engine

LS Mtron 1.9L 3-cyl dieselReference

Fuel tank28.0 LReference

Engine29.8 kWReference

LS Mtron L3C19-TReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke88 x 103 mmReference

EmissionsTier IVReference

Power29.8 kWReference

Fuel systemelectronic common rail direct injectionReference

Rated RPM2600Reference

Firing order1-3-2Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed mechanical shuttleReference

hydrostaticReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Four gears in three ranges with shuttle.Reference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)25.4 kWReference

Hydro PTO (claimed)23.9 kWReference

Typeopen centerReference

Rear valves1Reference

Pump flow31.0 lpmReference

Gear Steering flow15.9 lpmReference

Hydro Steering flow20.1 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)820 kgReference

Rear lift (at 24"/610mm)650 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase171 cmReference

Weight1391 kgReference

Front tire7x14Reference

Rear tire11.2x24Reference

Standard tires (ag)Front: 7x14. Rear: 11.2x24Reference

Lawn/turf front25x8.50-14Reference

Lawn/turf rear41x14.00-20Reference

Industrial front25x8.50-14Reference

Industrial rear43x16.00-20Reference

Length368 cmReference

Width168 cmReference

Height (ROPS)224 cmReference

Flange rear axleReference

CaseIH Farmall 40A attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps70Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

CaseIH BHA90A Backhoe

Backhoe typeCaseIH BHA90A BackhoeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
