Tractor · 2015Unverified
CaseIH Farmall 45C CVT
CaseIH Farmall 45C CVT — Farmall C Series · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Weight
4190 to 4940 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Compact Utility tractorReference
Original price$35,558 (2016 ROPS )Reference
Original price$44,450 (2016 Cab )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
FPT 2.2L 3-cyl dieselReference
Fuel tank49.2 LReference
Engine34.3 kWReference
FPT R7531E4Reference
turbocharged aftercooled dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke94 x 107 mmReference
EmissionsTier IVReference
Emission controlexhaust-gas recirculation with diesel particulate filterReference
Power34.3 kWReference
Fuel systemelectronic high-pressure common rail direct injectionReference
Air cleanerdry elementReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
Continuously Variable Transmission (CVT)Reference
TypeContinuously Variable Transmission (CVT)Reference
Gearsinfinite forward and reverseReference
Chain variator transmission.Reference
PTO & Hydraulics
PTO (claimed)26.8 kWReference
Typeopen centerReference
Rear valves1 or 2Reference
Mid valves2Reference
Pump flow37.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1606 kgReference
Rear lift (at 24"/610mm)1270 kgReference
Rear Armstelescopic link endsReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase186 cmReference
Weight4190 to 4940 poundsReference
Front tire8x16Reference
Rear tire14.9-24Reference
Standard tires (ag)Front: 8x16. Rear: 14.9-24Reference
Lawn/turf front27x10.50-15Reference
Lawn/turf rear44x18-20Reference
Lawn/turf front27/12LLx15Reference
Lawn/turf rear22.5LLx16.1Reference
Industrial front10-16.5Reference
Industrial rear17.5Lx24Reference
Length309 cmReference
Width173 cmReference
Height (ROPS)247 cmReference
Height (cab)235 cmReference
ROPS Weight1900 kgReference
Cab Weight2240 kgReference
Flange rear axleReference
CaseIH Farmall 45C attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps75Reference
Cab Charging amps90Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
