Tractor · 2010Unverified
CaseIH Farmall 55A
CaseIH Farmall 55A — Farmall A Series · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
3770 to 4385 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in IndiaReference
Two- or four-wheel driveReference
Differential lockmechanical rear differential lock with foot pedal, limited slip 4WD front axleReference
Steeringhydrostatic powerReference
Differential mechanical wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
ISM 2.2L 4-cyl dieselReference
Fuel tank51.1 LReference
Engine (gross)41.0 kWReference
ISMReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
EmissionsTier 3Reference
Power (gross)41.0 kWReference
Air cleanerdual dry elementReference
Compression23.4:1Reference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Power at rated engine speed36.8 kWReference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutch11-inch dry discReference
Four gears in two ranges. Synchronized mechanical shuttle with left-hand lever. Tractor must be stopped to shift gears or ranges.Reference
PTO & Hydraulics
PTO (claimed)35.0 kWReference
PTO (tested)36.8 kWReference
Typeopen center fixed displacement gear pumpReference
Valves1 or 2Reference
Pump flow43.9 lpmReference
Total flow64.0 lpmReference
Rear Type2/1Reference
Controlposition control with mechanical draft sensingReference
Rear lift (at 24"/610mm)1170 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Power at rated PTO speed36.5 kWReference
Dimensions
4WD Wheelbase220 cmReference
Weight3770 to 4385 poundsReference
Front tire6x16Reference
2WD Rear tire14.9x28Reference
2WD Standard tires (ag)Front: 6x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 9.5x24. Rear: 14.9x28Reference
2WD Length332 cmReference
4WD Length339 cmReference
Width167 cmReference
Height238 cmReference
Front tread145 to 184 cmReference
Rear tread143 to 184 cmReference
2WD Shipping1710 kgReference
4WD Shipping1849 kgReference
4WD Operating1989 kgReference
CaseIH Farmall 55A attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA800Reference
Battery volts12Reference
Test results
Diesel 8-speed 4WDDecember 7 - 9, 2011Link: Nebraska Tractor Test 2012 fileReference
PTO performanceReference
Fuel use13.2 l/hourReference
Fuel use12.9 l/hourReference
Speeds
Reverse speeds about 5% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
