Tractor · 2015Unverified

CaseIH Farmall 55C CVT

Name: CaseIH Farmall 55C CVT
Brand: CaseIH

CaseIH Farmall 55C CVT — Farmall C Series · 43 hp. Reference specifications; pending source verification.

The CaseIH Farmall 55C CVT is a compact tractor with a rated output of 43 hp. It was produced from 2015 to 2018 and features a 3-cylinder turbocharged diesel liquid-cooled engine, powering four-wheel drive through a continuously variable transmission. The listed weight of this model is between 4190 and 4940 pounds, suitable for tasks of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

43 hp

Weight

4190 to 4940 pounds

Catalogue coverage

Variants represented

Richest spec table

66 rows

Recorded power

43 hp

Recorded weight

1900 kg

Transmissions

Continuously Variable Transmission (CVT)

Production years

2015-2018

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Compact Utility tractorReference

Original price$38,877 (2016 ROPS )Reference

Original price$47,769 (2016 Cab )Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

FPT 2.2L 3-cyl dieselReference

Fuel tank49.2 LReference

Engine40.3 kWReference

FPT R7531E4Reference

turbocharged aftercooled dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke94 x 107 mmReference

EmissionsTier IVReference

Emission controlexhaust-gas recirculation with diesel particulate filterReference

Power40.3 kWReference

Fuel systemelectronic high-pressure common rail direct injectionReference

Air cleanerdry elementReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

Continuously Variable Transmission (CVT)Reference

TypeContinuously Variable Transmission (CVT)Reference

Gearsinfinite forward and reverseReference

Chain variator transmission.Reference

PTO & Hydraulics

PTO (claimed)32.1 kWReference

Typeopen centerReference

Rear valves1 or 2Reference

Mid valves2Reference

Pump flow37.1 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)1606 kgReference

Rear lift (at 24"/610mm)1270 kgReference

Rear Armstelescopic link endsReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase186 cmReference

Weight4190 to 4940 poundsReference

Front tire8x16Reference

Rear tire14.9-24Reference

Standard tires (ag)Front: 8x16. Rear: 14.9-24Reference

Lawn/turf front27x10.50-15Reference

Lawn/turf rear44x18-20Reference

Lawn/turf front27/12LLx15Reference

Lawn/turf rear22.5LLx16.1Reference

Industrial front10-16.5Reference

Industrial rear17.5Lx24Reference

Length309 cmReference

Width173 cmReference

Height (ROPS)247 cmReference

Height (cab)235 cmReference

ROPS Weight1900 kgReference

Cab Weight2240 kgReference

Flange rear axleReference

CaseIH Farmall 55C attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps75Reference

Cab Charging amps90Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
