Tractor · 2017Unverified

CaseIH Farmall 55C Series II

Name: CaseIH Farmall 55C Series II
Brand: CaseIH

CaseIH Farmall 55C Series II — Farmall C Series · 47 hp. Reference specifications; pending source verification.

The CaseIH Farmall 55C Series II is a compact tractor with a rated output of 47 hp. It was manufactured in 2017 and features a 3-cylinder turbocharged diesel liquid-cooled engine. The tractor is equipped with four-wheel drive and a hydrostatic transmission, with a listed weight range of 3770 to 4453 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

47 hp

Weight

3770 to 4453 pounds

Catalogue coverage

Variants represented

Richest spec table

78 rows

Recorded power

47 hp

Recorded weight

1710 kg

Transmissions

16-speed mechanical shuttle

Production years

2017-2017

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Compact Utility tractorReference

Original price$36,310 (2020 shuttle ROPS )Reference

Original price$43,362 (2020 hydro Cab )Reference

Original price$49,449 (2025 shuttle ROPS )Reference

Original price$61,513 (2025 hydro Cab )Reference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Variants

Boomer 55similar New Holland modelReference

Engine

LS Mtron 1.9L 3-cyl dieselReference

ROPS Fuel tank40.1 LReference

Cab Fuel tank46.9 LReference

Engine41.0 kWReference

LS Mtron L3C19-TReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke88 x 103 mmReference

EmissionsTier IVReference

Emission controlexhaust gas recirculation with DOC and DPFReference

Power41.0 kWReference

Fuel systemelectronic direct-injection common railReference

Rated RPM2600Reference

Firing order1-3-2Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed mechanical shuttleReference

hydrostaticReference

Typemechanical shuttleReference

Gears16 forward and reverseReference

Four synchronized speeds in four ranges with mechanical shuttle.Reference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)34.8 kWReference

Hydro PTO (claimed)32.8 kWReference

Typeopen centerReference

Valves1 or 2Reference

Pump flow31.0 lpmReference

Gear Steering flow15.9 lpmReference

Hydro Steering flow20.1 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at ends)1250 kgReference

Rear lift (at 24"/610mm)1119 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase185 cmReference

Weight3770 to 4453 poundsReference

Front tire9.5x16Reference

Rear tire13.6-24Reference

Standard tires (ag)Front: 9.5x16. Rear: 13.6-24Reference

Lawn/turf front28x8.50-15Reference

Lawn/turf rear41x14.00-20Reference

Industrial front12-16.5Reference

Industrial rear17.5Lx24Reference

Length325 cmReference

Width175 cmReference

Height (ROPS)249 cmReference

Height (cab)236 cmReference

ROPS Weight1710 kgReference

Cab Weight2019 kgReference

Flange rear axleReference

CaseIH Farmall 55C attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps70Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

CaseIH BHA102 Backhoe

Backhoe typeCaseIH BHA102 BackhoeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
