The CaseIH Farmall 80CL is a mid-range tractor with an approximate engine rating of 65 horsepower. It was manufactured in 2024. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It is suitable for operations on land up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
65 hp
Transmissions
16-speed power shuttle
Production years
2024-2024
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerCaseIH (a part of CNH)Reference
Orchard/Vineyard tractorReference
Four-wheel driveReference
ROPS. Cab optional.Reference
Engine
FPT 3.4L 4-cyl dieselReference
Cab Fuel tank74.9 LReference
ROPS Fuel tank65.1 LReference
Engine55.2 kWReference
FPTReference
turbocharged aftercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsTier IVReference
Power55.2 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed power shuttleReference
32-speed partial power shiftReference
Typepower shuttleReference
Gears16 forward and reverseReference
Clutchwet discReference
Typepartial power shiftReference
Gears32 forward and 16 reverseReference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Valves3Reference
Pump flow64.0 lpmReference
Pump flow79.5 lpmReference
Rear TypeIIReference
Rear lift650 kgReference
Rear PTO Type540 (1.375)Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase167 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
