Tractor · 2017Unverified

CaseIH Farmall 80V

Name: CaseIH Farmall 80V
Brand: CaseIH

CaseIH Farmall 80V — Farmall V Series · 74 hp. Reference specifications; pending source verification.

The CaseIH Farmall 80V is a tractor with an output of 74 hp, positioning it within the middle of its class in terms of power. It was produced in 2017 and features a 4-cylinder turbocharged diesel liquid-cooled engine, which powers four-wheel drive through a powershift transmission. The listed weight of the tractor ranges from 5108 to 5975 pounds. Its intended applications include tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

74 hp

Weight

5108 to 5975 pounds

Catalogue coverage

Variants represented

Richest spec table

67 rows

Recorded power

74 hp

Transmissions

16-speed partially synchronized

Production years

2017-2017

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Orchard/Vineyard tractorReference

Original price$55,859 (2019 Syncro ROPS 2WD )Reference

Original price$72,020 (2019 Hi-Lo Cab 4WD )Reference

Two- or four-wheel driveReference

Final drivesinboard planetaryReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS. Cab optional with air-conditioning.Reference

Engine

FPT 3.4L 4-cyl dieselReference

Fuel tank67.0 LReference

Engine (gross)55.2 kWReference

FPTReference

turbocharged aftercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke99 x 110 mmReference

EmissionsInterim Tier IVReference

Power (gross)55.2 kWReference

Fuel systemelectronic high-pressure common railReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed partially synchronizedReference

16-speed power shiftReference

32-speed Hi-Lo power shiftReference

Typepartially synchronizedReference

Gears16 forward and reverseReference

Four synchronized gears in four non-synchronized ranges with mechanical shuttle.Reference

Typepower shiftReference

TypeHi-Lo power shiftReference

Gears32 forward and 16 reverseReference

PTO & Hydraulics

PTO (claimed)48.5 kWReference

Typeopen centerReference

Rear valves2 or 3Reference

Mid valves2Reference

Pump flow64.0 lpmReference

Pump flow79.9 lpmReference

Steering flow43.1 lpmReference

Rear TypeII/IReference

Rear lift (at ends)2600 kgReference

Rear lift (at 24"/610mm)1714 kgReference

Front HitchoptionalReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase243 cmReference

Weight5108 to 5975 poundsReference

Front tire6.00-16Reference

2WD Rear tire11.2R24Reference

2WD Standard tires (ag)Front: 6.00-16. Rear: 11.2R24Reference

4WD Standard tires (ag)Front: 8.0/75-15. Rear: 11.2R24Reference

Length387 cmReference

Width107 cmReference

Height (ROPS)228 cmReference

Height (cab)232 cmReference

Ground clearance28 cmReference

Flange rear axleReference

2WD Cab2458 kgReference

2WD ROPS2316 kgReference

4WD Cab2710 kgReference

4WD ROPS2567 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
