Tractor · 2003Unverified

CaseIH Farmall DX21

Name: CaseIH Farmall DX21
Brand: CaseIH

CaseIH Farmall DX21 — Farmall DX Series · 21 hp. Reference specifications; pending source verification.

The CaseIH Farmall DX21 is a tractor with a rated output of 21 hp, categorising it as one of the more compact options in its class. Production of the tractor spanned the period from 2003 to 2005. It features a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. The listed weight of the tractor ranges from 1495 to 1592 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

21 hp

Weight

1495 to 1592 pounds

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

21 hp

Recorded weight

722 kg

Transmissions

9-speed gear

Production years

2003-2005

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Soft cab optional.Reference

Variants

TC21DAsimilar New Holland modelReference

Engine

Shibaura 1.0L 3-cyl dieselReference

Fuel tank20.1 LReference

Engine (gross)15.7 kWReference

ShibauraReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.0 LReference

Bore/Stroke77 x 72 mmReference

Power (gross)15.7 kWReference

StarterelectricReference

Starter volts12Reference

Transmission

9-speed gearReference

hydrostaticReference

TypegearReference

Gears9 forward and 3 reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Gear PTO (claimed)12.7 kWReference

Hydro PTO (claimed)11.9 kWReference

Typeopen centerReference

Valves2Reference

Pump flow18.5 lpmReference

Total flow29.0 lpmReference

Steering flow10.4 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)573 kgReference

Gear Rear PTOtransmissionReference

Hydro Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Gear Mid PTOtransmissionReference

Hydro Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase146 cmReference

Weight1495 to 1592 poundsReference

Weight722 kgReference

Weight678 kgReference

CaseIH Farmall DX21 attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

Front-end loaderReference

BackhoeReference

CaseIH BHX172 Backhoe

Backhoe typeCaseIH BHX172 BackhoeReference

Digging depth182 cmReference

Bucket force1304 kgReference

Dipperstick force791 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
