Tractor · 2006Unverified

CaseIH Farmall DX22E

Name: CaseIH Farmall DX22E
Brand: CaseIH

CaseIH Farmall DX22E — DXE Series · 22 hp. Reference specifications; pending source verification.

The CaseIH Farmall DX22E is a tractor with a rated output of 22 hp, offering a compact design within its class. Production of the Farmall DX22E took place from 2006 to 2007. It features a 3-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission for four-wheel drive. The tractor's listed weight is 596 kg, suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Weight

596 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

22 hp

Recorded weight

596 kg

Transmissions

hydrostatic

Production years

2006-2007

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post fixed ROPS.Reference

Variants

TZ22DAsimilar New Holland modelReference

SX21similar Shibaura modelReference

Engine

Shibaura 1.0L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine (gross)16.4 kWReference

Shibaura S753Reference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.0 LReference

Bore/Stroke75 x 72 mmReference

Power (gross)16.4 kWReference

Compression24:1Reference

Rated RPM3000Reference

Idle RPM1380-3200Reference

Firing order1-2-3Reference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

PTO (claimed)12.7 kWReference

Typeopen centerReference

Pump flow14.2 lpmReference

Total flow20.8 lpmReference

Steering flow7.0 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)317 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2200Reference

Dimensions

Wheelbase139 cmReference

Weight596 kgReference

Length244 cmReference

Width116 cmReference

Height (ROPS)184 cmReference

CaseIH Farmall DX22E attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
