The CaseIH Farmall DX34 is a tractor with a rated power of 29 hp, situated at the lighter end of its class. Production of the Farmall DX34 took place from 2006 to 2008. The tractor features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. Its listed operating weight is 1145 kg, and it is suitable for operations covering up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
29 hp
Weight
1145 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
29 hp
Recorded weight
1145 kg
Transmissions
hydrostatic
Production years
2006-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorCaseIHReference
ManufacturerShibauraReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Two-post ROPS.Reference
Variants
TC34DAsimilar New Holland modelReference
Engine
Shibaura 1.7L 3-cyl dieselReference
Fuel tank27.6 LReference
Engine26.1 kWReference
Shibaura N843LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.7 LReference
Bore/Stroke84 x 100 mmReference
Power26.1 kWReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)21.6 kWReference
Typeopen centerReference
Pump flow27.3 lpmReference
Total flow46.6 lpmReference
Steering flow19.3 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)741 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase160 cmReference
Weight1145 kgReference
Length285 cmReference
Width137 cmReference
Height (ROPS)223 cmReference
CaseIH DX34 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
