Tractor · 2004Unverified

CaseIH Farmall DX48

Name: CaseIH Farmall DX48
Brand: CaseIH

CaseIH Farmall DX48 — DX Series · 48 hp. Reference specifications; pending source verification.

The CaseIH Farmall DX48 is a tractor with a rated output of 48 hp, falling within a compact category in its class. It was manufactured from 2004 to 2008. This model is equipped with a 4-cylinder diesel liquid-cooled engine, which transmits power to four-wheel drive via a 12-speed gearbox, and has a listed weight of 1957 kg. It is designed for use in areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

48 hp

Weight

1957 kg

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

48 hp

Recorded weight

1957 kg

Transmissions

12-speed synchronized shuttle

Production years

2004-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Compact Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Independent mechanical wet disc brakesReference

Two-post folding ROPS.Reference

Variants

TC48DAsimilar New Holland modelReference

Engine

Shibaura 2.2L 4-cyl dieselReference

Fuel tank51.1 LReference

Engine (gross)35.8 kWReference

Shibaura N844LReference

dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement2.2 LReference

Bore/Stroke84 x 100 mmReference

Power (gross)35.8 kWReference

Air cleanerdual paper elementsReference

Compression22.4:1Reference

Rated RPM2800Reference

Starter volts12Reference

Power at rated engine speed30.6 kWReference

Transmission

12-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

PTO (claimed)29.8 kWReference

PTO (tested)30.6 kWReference

Typeopen centerReference

Total flow66.4 lpmReference

Rear TypeII/IReference

Rear lift (at 24"/610mm)1571 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2475Reference

Power at rated PTO speed28.8 kWReference

Dimensions

Wheelbase189 cmReference

Weight1957 kgReference

Operating weight1957 kgReference

CaseIH Farmall DX48 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

CaseIH BHX190 Backhoe

Backhoe typeCaseIH BHX190 BackhoeReference

Digging depth228 cmReference

Bucket force1230 kgReference

Dipperstick force884 kgReference

CaseIH BHX1102 Backhoe

Backhoe typeCaseIH BHX1102 BackhoeReference

Digging depth259 cmReference

Bucket force1610 kgReference

Dipperstick force1009 kgReference

CaseIH BHX1114 Backhoe

Backhoe typeCaseIH BHX1114 BackhoeReference

Digging depth289 cmReference

Bucket force2013 kgReference

Dipperstick force1270 kgReference

Test results

Diesel 12-speed 4WDApril 27 - 30, 2004Link: Nebraska Tractor Test 1836A fileReference

PTO performanceReference

Fuel use12.9 l/hourReference

Fuel use11.4 l/hourReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
