Tractor · 2004Unverified

CaseIH JX1060C

Name: CaseIH JX1060C
Brand: CaseIH

CaseIH JX1060C — JXC Series · 57 hp. Reference specifications; pending source verification.

The CaseIH JX1060C is a tractor specified at 57 hp, positioning it towards the lighter end of its class. It was manufactured from 2004 to 2008. This tractor features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 16-speed gearbox. Its listed operating weight ranges from 6065 to 6590 pounds, making it suitable for operations covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

57 hp

Max power

36.0 kW

Weight

6065 to 6590 pounds

Catalogue coverage

Variants represented

Richest spec table

71 rows

Recorded power

57 hp

Transmissions

16-speed mechanical shuttle

Production years

2004-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Utility tractorReference

Built in Jesi, ItalyReference

Two- or four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

Iveco 2.9L 3-cyl dieselReference

Fuel tank73.8 LReference

Engine (gross)42.5 kWReference

Drawbar (tested)28.6 kWReference

IvecoReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke104 x 115 mmReference

Power (gross)42.5 kWReference

Fuel systemdirect injectionReference

Air cleanerdual paper elementsReference

Pre-heatingthermostartReference

Compression18.0:1Reference

Rated RPM2300Reference

Starter volts12Reference

Max power36.0 kWReference

Power at rated engine speed35.2 kWReference

Max power28.6 kWReference

Transmission

16-speed mechanical shuttleReference

16-speed power shuttleReference

Typemechanical shuttleReference

Gears16 forward and reverseReference

Typepower shuttleReference

PTO & Hydraulics

PTO (claimed)33.6 kWReference

PTO (tested)36.0 kWReference

Typeopen centerReference

Pressure190.0 barReference

Valves1 to 4Reference

Pump flow46.9 lpmReference

Pump flow64.0 lpmReference

Steering flow28.0 lpmReference

Steering flow35.6 lpmReference

Rear TypeIIReference

Controlmechanical lower-link draft sensing.Reference

Rear lift1796 kgReference

Rear PTOindependentReference

Clutchmechanical dry discReference

Rear PTO Type540 (1.375)Reference

Power at rated PTO speed35.3 kWReference

Dimensions

2WD Wheelbase213 cmReference

4WD Wheelbase206 cmReference

Weight6065 to 6590 poundsReference

2WD Length395 cmReference

4WD Length391 cmReference

Width176 cmReference

Operating2751 kgReference

Operating2989 kgReference

Ballasted3479 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps65Reference

Cab Charging amps85Reference

Battery CCA730Reference

Battery volts12Reference

CaseIH JX1060C Height

ROPS242 cmReference

ROPS192 cmReference

Cab232 cmReference

Test results

Diesel 16-speed 4WDMarch 1 - 31, 2004Link: OCED Tractor Test 2156 fileReference

PTO performanceReference

Fuel use11.4 l/hourReference

Drawbar performanceReference

Gear 9 used for power test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
