Tractor · 2004Unverified

CaseIH JX1070C

Name: CaseIH JX1070C
Brand: CaseIH

CaseIH JX1070C — JXC Series · 70 hp. Reference specifications; pending source verification.

The CaseIH JX1070C is a tractor model with a rated power output of approximately 70 hp, a mid-range figure for its class. It was produced from 2004 to 2008 and features a 3-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a 16-speed gearbox. The tractor has a listed operating weight of 6085 to 6615 pounds and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

70 hp

Max power

45.2 kW

Weight

6085 to 6615 pounds

Catalogue coverage

Variants represented

Richest spec table

73 rows

Recorded power

70 hp

Transmissions

16-speed mechanical shuttle

Production years

2004-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Utility tractorReference

Built in Jesi, ItalyReference

Two- or four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

Iveco 2.9L 3-cyl dieselReference

Fuel tank73.8 LReference

Engine (gross)52.2 kWReference

Drawbar (tested)38.0 kWReference

IvecoReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke104 x 115 mmReference

Power (gross)52.2 kWReference

Fuel systemdirect injectionReference

Air cleanerdual paper elementsReference

Pre-heatingthermostartReference

Compression18.0:1Reference

Rated RPM2300Reference

Starter volts12Reference

Max power45.2 kWReference

Power at rated engine speed44.6 kWReference

Max power38.0 kWReference

Transmission

16-speed mechanical shuttleReference

16-speed power shuttleReference

Typemechanical shuttleReference

Gears16 forward and reverseReference

Typepower shuttleReference

PTO & Hydraulics

PTO (claimed)42.5 kWReference

PTO (tested)45.2 kWReference

Typeopen centerReference

Pressure190.0 barReference

Valves1 to 4Reference

Pump flow46.9 lpmReference

Pump flow64.0 lpmReference

Steering flow28.0 lpmReference

Steering flow35.6 lpmReference

Rear TypeIIReference

Controlmechanical lower-link draft sensing.Reference

Rear lift1796 kgReference

Rear PTOindependentReference

Clutchmechanical dry discReference

Rear PTO Type540 (1.375)Reference

Power at rated PTO speed44.9 kWReference

Dimensions

2WD Wheelbase213 cmReference

4WD Wheelbase206 cmReference

Weight6085 to 6615 poundsReference

2WD Length395 cmReference

4WD Length391 cmReference

Width176 cmReference

Operating2760 kgReference

Operating3000 kgReference

Ballasted3490 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps65Reference

Cab Charging amps85Reference

Battery CCA730Reference

Battery volts12Reference

CaseIH JX1070C Height

ROPS242 cmReference

ROPS192 cmReference

Cab232 cmReference

Test results

Diesel 16-speed 4WDFebruary 1 - May 1, 2004Link: OCED Tractor Test 2162 fileReference

PTO performanceReference

Fuel use14.8 l/hourReference

Fuel use14.4 l/hourReference

Drawbar performanceReference

Fuel use14.0 l/hourReference

Gear 10 used for power test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
