Tractor · 2005Unverified
CaseIH JX1095C
CaseIH JX1095C — JXC Series · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Max power
62.5 kW
Weight
3166 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in Jesi, ItalyReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
CNH 4.5L 4-cyl dieselReference
Fuel tank88.9 LReference
Engine (gross)67.1 kWReference
Drawbar (tested)55.4 kWReference
CNHReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke104 x 132 mmReference
Power (gross)67.1 kWReference
Fuel systemdirect injectionReference
Air cleanerdual paper elementsReference
Pre-heatingthermostartReference
Compression17.5:1Reference
Rated RPM2300Reference
Starter volts12Reference
Max power62.5 kWReference
Power at rated engine speed62.3 kWReference
Max power55.4 kWReference
Transmission
12-speed mechanical shuttleReference
12-speed power shuttleReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Typepower shuttleReference
PTO & Hydraulics
PTO (claimed)57.4 kWReference
PTO (tested)62.5 kWReference
Typeopen centerReference
Pressure190.0 barReference
Valves1 to 4Reference
Pump flow64.0 lpmReference
Steering flow35.6 lpmReference
Rear TypeIIReference
Controlmechanical lower-link draft sensing.Reference
Rear lift1796 kgReference
Rear PTOindependentReference
Clutchmechanical dry discReference
Rear PTO Type540 (1.375)Reference
Power at rated PTO speed62.2 kWReference
Dimensions
Wheelbase218 cmReference
Weight3166 kgReference
Length398 cmReference
Width176 cmReference
Operating weight3166 kgReference
Ballasted weight3649 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA730Reference
Battery volts12Reference
CaseIH JX1095C Height
ROPS242 cmReference
ROPS192 cmReference
Cab232 cmReference
Test results
Diesel 12-speed 4WDSeptember 1 - October 1, 2005Link: OCED Tractor Test 2347 fileReference
PTO performanceReference
Fuel use19.7 l/hourReference
Fuel use19.3 l/hourReference
Drawbar performanceReference
Gear 8 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
