Tractor · 2005Unverified
CaseIH JX1095N
CaseIH JX1095N — JXN Series · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
5820 to 6107 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount foldable ROPS. Cab optional.Reference
Engine
Case IH 3.9L 4-cyl dieselReference
Fuel tank56.8 LReference
Engine (gross)67.9 kWReference
Case IHReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
EmissionsTier IIReference
Power (gross)67.9 kWReference
Fuel systemmechanical direct injectionReference
Rated RPM2300Reference
Torque358.0 NmReference
Torque RPM1400Reference
Starter volts12Reference
Transmission
16-speedReference
Transmissionmechanical shuttleReference
Gears16 forward and reverseReference
Four synchronized gears in four ranges with mechanical shuttle.Reference
PTO & Hydraulics
PTO (claimed)59.7 kWReference
Typeopen centerReference
Pressure180.0 barReference
Rear valves2Reference
Pump flow64.0 lpmReference
Total flow88.6 lpmReference
Steering flow24.6 lpmReference
Rear TypeIIReference
Controlmechanical lower-link draft sensingReference
Rear lift1797 kgReference
Rear PTOindependentReference
Clutchmechanical dry discReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase217 cmReference
Weight5820 to 6107 poundsReference
Length401 cmReference
Width135 cmReference
Ground clearance26 cmReference
ROPS2639 kgReference
Cab2770 kgReference
Max front axle1999 kgReference
Max rear axle3000 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery CCA800Reference
Battery volts12Reference
CaseIH JX1095N Height
Hood129 cmReference
ROPS232 cmReference
Cab230 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
