Tractor · 2007Unverified

CaseIH JX60

Name: CaseIH JX60
Brand: CaseIH

CaseIH JX60 — JX Series · 55 hp. Reference specifications; pending source verification.

The CaseIH JX60 is a tractor with a rated power output of 55 horsepower, positioning it at the lighter end of its class. This model was produced from 2007 to 2008. It features a 3-cylinder diesel liquid-cooled engine paired with four-wheel drive and a hydrostatic transmission. The operating weights for the CaseIH JX60 range from 5152 to 6365 pounds, making it suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

5152 to 6365 pounds

Catalogue coverage

Variants represented

Richest spec table

65 rows

Recorded power

55 hp

Transmissions

12-speed mechanical shuttle

Production years

2007-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCaseIHReference

ManufacturerTurk TractorReference

Utility tractorReference

Built in Ankara, TurkeyReference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

Steeringhydrostatic powerReference

Brakeshydraulic wet disc (USA)Reference

Brakesmechanical wet discReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Iveco 2.9L 3-cyl dieselReference

Fuel tank90.1 LReference

Engine (gross)41.0 kWReference

IvecoReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Power (gross)41.0 kWReference

Fuel systemdirect injection with mechanical governorReference

Air cleanerdual dry elementsReference

Rated RPM2500Reference

Torque207.1 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed mechanical shuttleReference

20-speed mechanical shuttle with creeperReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

Three ranges with four gears per range. Left-hand reverser requires use of clutch to change directionsReference

Typemechanical shuttle with creeperReference

Gears20 forward and 12 reverseReference

PTO & Hydraulics

PTO (claimed)33.6 kWReference

Typeopen centerReference

Pressure190.0 barReference

Valves1 to 3, 1 mid optionalReference

Pump flow40.1 lpmReference

Pump flow51.5 lpmReference

Total flow82.1 lpmReference

Steering flow30.7 lpmReference

Rear TypeII/IReference

Controlmechanical draft sensingReference

Rear lift (at 24"/610mm)1818 kgReference

Rear PTOindependentReference

Clutchmechanical dry discReference

Rear PTO Type540Reference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase218 cmReference

Wheelbase213 cmReference

Weight5152 to 6365 poundsReference

Length391 cmReference

Length386 cmReference

Width180 cmReference

Height (ROPS)246 cmReference

Height (cab)254 cmReference

Shipping2336 kgReference

Shipping2636 kgReference

Shipping2587 kgReference

Shipping2887 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps85Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
