Tractor · 2002Unverified
CaseIH JX80U
CaseIH JX80U — JXU Maxxima Series · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Max power
40.5 kW
Weight
7855 to 8330 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic front and rearReference
Power steeringReference
Independent hydraulic wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
Iveco 3.9L 4-cyl dieselReference
Fuel tank126.8 LReference
Engine (gross)55.2 kWReference
Drawbar (tested)40.5 kWReference
IvecoReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power (gross)55.2 kWReference
Fuel systemmechanical direct injectionReference
Air cleanerdual paper elementsReference
Pre-heatingthermostartReference
Compression17.0:1Reference
Rated RPM2500Reference
Starter volts12Reference
Power at rated engine speed50.2 kWReference
Max power40.5 kWReference
Transmission
24-speed two-speed power shiftReference
24-speed power shuttleReference
20-speed syncromeshReference
Typetwo-speed power shiftReference
Gears24 forward and 12 reverseReference
Two-speed power shift with left-hand synchronized shuttle.Reference
Typepower shuttleReference
Gears24 forward and reverseReference
Four gears (1-4) in three ranges (I, II, III) with push-button power shift and power shuttleReference
TypesyncromeshReference
Gears20 forward and 12 reverseReference
PTO & Hydraulics
PTO (claimed)49.2 kWReference
PTO (tested)50.2 kWReference
Typeopen centerReference
Valves2 or 3Reference
Pump flow54.9 lpmReference
Total flow75.7 lpmReference
Steering flow20.8 lpmReference
Rear TypeIIReference
Controlmechanical lower-link draft sensingReference
Rear lift3583 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000Reference
Power at rated PTO speed48.5 kWReference
Dimensions
2WD Wheelbase234 cmReference
4WD Wheelbase231 cmReference
Weight7855 to 8330 poundsReference
2WD Cab3563 kgReference
4WD Cab3778 kgReference
2WD Cab Ballasted4311 kgReference
4WD Cab Ballasted4524 kgReference
CaseIH JX80U attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps85Reference
Battery CCA960Reference
Battery volts12Reference
Attachment overview
CaseIH LX132 loaderReference
CaseIH LX152 loaderReference
CaseIH JX80U Height
ROPS276 cmReference
Cab262 cmReference
Exhaust278 cmReference
Test results
Diesel 24-speed 4WDDecember 1, 2002 - December 1, 2003Link: OCED Tractor Test 2077 fileReference
PTO performanceReference
Fuel use15.5 l/hourReference
Fuel use14.4 l/hourReference
Drawbar performanceReference
Gear 12 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
