Tractor · 2014Unverified
CaseIH Magnum 240
CaseIH Magnum 240 — Model year 2014-20192019-2027 · 240 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
240 hp
Max power
167.7 kW
Weight
10117 kg
Hover a source tag to verify
Overview
ManufacturerCaseIH (a part of CNH)Reference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Original price$225,400 (2014 CVT )Reference
Original price$240,377 (2017 CVT )Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Power steeringReference
Hydraulic wet disc brakesReference
Magnum cab standard with air-conditioning. Optional cab suspension.Reference
Engine
FPT 6.7L 6-cyl dieselReference
Fuel tank605.6 LReference
Exhaust fluid (DEF)66.2 LReference
Engine (gross)179.0 kWReference
Engine (max)201.3 kWReference
Drawbar (tested)139.2 kWReference
FPTReference
wastegate turbocharged air-to-air intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
EmissionsTier 4Reference
Emission controlselective catalytic reduction (SCR)Reference
Rated Power (gross)179.0 kWReference
Maximum Power (gross)201.3 kWReference
Fuel systemelectronic high pressure common rail direct injectionReference
Cooling systemviscous fanReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Max power167.7 kWReference
Power at rated engine speed154.5 kWReference
Max power139.2 kWReference
Transmission
continuously variable transmission (CVT)Reference
Typecontinuously variable transmission (CVT)Reference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)152.9 kWReference
PTO (tested)167.7 kWReference
Typepressure flow compensatingReference
Rear valves3 to 5Reference
Pump flow162.8 lpmReference
Rear TypeIII/IIINReference
Controlelectronic lower link draft sensingReference
Rear lift (at 24"/610mm)6395 kgReference
DrawbarCat. 3Reference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed166.4 kWReference
Dimensions
Wheelbase299 cmReference
Weight10117 kgReference
Front tire380/85R34Reference
Rear tire480/80R46Reference
Ag front380/85R34Reference
Ag rear480/80R46Reference
Length594 cmReference
Height (cab)326 cmReference
Operating weight10117 kgReference
Front axle4WDReference
Front axleSuspended 4WDReference
Magnum 240 Serial Number Location
Serial number plate on the front right of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Test results
Diesel CVT 4WDMay 14 - June 8, 2015Link: OCED Tractor Test 2121 fileReference
PTO performanceReference
Fuel use45.8 l/hourReference
Fuel use44.7 l/hourReference
Drawbar performanceReference
Pull at 9 KPHReference
Max pull10103 kgReference
Pull at 5 KPHReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
