Tractor · 2012Unverified
CaseIH Magnum 370
CaseIH Magnum 370 — Magnum Series · 367 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
367 hp
Weight
14147 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Four-wheel driveReference
Final drivesinboard planetaryReference
SteeringpowerReference
Cab standard with air-conditioning.Reference
Engine
FPT 8.7L 6-cyl dieselReference
Fuel tank575.3 LReference
Exhaust fluid (DEF)89.3 LReference
Engine (gross)273.7 kWReference
Engine (max)312.4 kWReference
FPTReference
electronic variable geometry turbocharger dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement8.7 LReference
Bore/Stroke117 x 135 mmReference
EmissionsInterim Tier 4Reference
Emission controlselective catalytic reduction (SCR)Reference
Rated Power (gross)273.7 kWReference
Maximum Power (gross)312.4 kWReference
Fuel systemelectronic high pressure common rail direct injectionReference
Cooling systemBorgWarner Visctronic fanReference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously variable transmissionReference
TransmissionCVTReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)227.4 kWReference
Typevariable displacement pressure flow compensating (PFC)Reference
Valves4 to 6Reference
Pump flow166.5 lpmReference
Pump flow223.3 lpmReference
Pump flow283.9 lpmReference
Rear TypeIVN/IIIReference
Rear TypeIII (optional)Reference
Controlelectronic lower link draft sensningReference
Rear lift (at 24"/610mm)7938 kgReference
Rear lift (at 24"/610mm)6520 kgReference
Rear Armsadjustable quick couplerReference
DrawbarCat. 4Reference
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase314 cmReference
Weight14147 kgReference
Front tire420/85R34Reference
Rear tire480/80R50 (duals)Reference
Standard tires (ag)Front: 420/85R34. Rear: 480/80R50 (duals)Reference
Width304 cmReference
Max weight18144 kgReference
Front axle4WDReference
Front axleSuspended 4WDReference
Bar rear axle127 by 3048 mmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
