Tractor · 2005Unverified
CaseIH MXU130 Value
CaseIH MXU130 Value — MXU Maxxum Series · 131 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
131 hp
Weight
10060 to 11406 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Utility tractorReference
Built in Basildon, EnglandReference
Two- or four-wheel driveReference
Final drivesplanetary inboardReference
Differential lockelectro-hydraulicReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
ROPS. Cab optional.Reference
Engine
CNH 6.7L 6-cyl dieselReference
Fuel tank253.6 LReference
Engine (gross)97.7 kWReference
CNHReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
Power (gross)97.7 kWReference
Fuel systemmechanical rotary distributorReference
Air cleanerdual paper elementsReference
Pre-heatinggrid heaterReference
Compression17.0:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed partial powershiftReference
Typepartial powershiftReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)82.0 kWReference
Typeopen centerReference
Valves2 to 3Reference
Pump flow62.8 lpmReference
Total flow102.6 lpmReference
Steering flow39.7 lpmReference
Rear Type2Reference
Controlmechanical lower linkReference
Rear lift (at 24"/610mm)3406 kgReference
Rear lift (at 24"/610mm)3997 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
2WD Wheelbase265 cmReference
4WD Wheelbase265 cmReference
Weight10060 to 11406 poundsReference
Front tire10.00x16Reference
Rear tire18.4R38 (2WD)Reference
Standard tires (ag)Front: 10.00x16. Rear: 18.4R38 (2WD)Reference
Standard tires (ag)Front: 14.9R28. Rear: 18.4R38 (4WD)Reference
Height (ROPS)289 cmReference
Height (cab)281 cmReference
2WD ROPS4563 kgReference
4WD ROPS4731 kgReference
2WD Cab4692 kgReference
4WD Cab5173 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Battery CCA800Reference
Battery CCA960 (optional)Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
