Tractor · 2001Unverified

CaseIH PJ75

Name: CaseIH PJ75
Brand: CaseIH

CaseIH PJ75 — PJ Series · 75 hp. Reference specifications; pending source verification.

The CaseIH PJ75 is a tractor with a power rating of 75 hp, placing it in the middle of its class. Manufactured from 2001 to 2004, this model is equipped with a 4-cylinder diesel air-cooled engine. The drive system consists of four-wheel drive with a hydrostatic transmission. The tractor's weight is listed at 2575 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Weight

2575 kg

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

75 hp

Recorded weight

2575 kg

Transmissions

12-speed synchromesh

Production years

2001-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Utility tractorReference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Four-post ROPS.Reference

Variants

PJ75utilityReference

PJN75orchardReference

PJV75vineyardReference

Engine

4.0L 4-cyl dieselReference

Fuel tank60.0 LReference

Engine55.9 kWReference

dieselReference

4-cylinderReference

air-cooledReference

Displacement4.0 LReference

EmissionsTier IReference

Power55.9 kWReference

Rated RPM2350Reference

Torque276.1 NmReference

Torque RPM1400Reference

Starter typeelectricReference

Transmission

12-speed synchromeshReference

24-speedReference

24-speed two-speed power shiftReference

TypesynchromeshReference

Gears12 forward and reverseReference

Gears24 forward and reverseReference

Typetwo-speed power shiftReference

PTO & Hydraulics

Valves3Reference

Pump flow39.4 lpmReference

Steering flow19.7 lpmReference

Rear TypeIReference

Controltop-link draft sensingReference

Rear lift (at ends)2399 kgReference

Rear PTOindependentReference

Dimensions

2WD Wheelbase211 cmReference

4WD Wheelbase222 cmReference

Weight2575 kgReference

Rear tire380/70R28Reference

Ag rear380/70R28Reference

2WD Length381 cmReference

4WD Length380 cmReference

Width177 cmReference

Height (ROPS)213 cmReference

4WD Weight2575 kgReference

Ground clearance28 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
