Tractor · 2001Unverified

CaseIH PJV55

Name: CaseIH PJV55
Brand: CaseIH

CaseIH PJV55 — PJ Series · 55 hp. Reference specifications; pending source verification.

The CaseIH PJV55 is a tractor model with a power output of approximately 55 horsepower, positioning it at the lighter end of its class. This model was in production from 2001 to 2004 and features a 3-cylinder diesel air-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight falls within the range of 4806 to 5181 pounds, making it suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

4806 to 5181 pounds

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

55 hp

Recorded weight

2350 kg

Transmissions

12-speed synchromesh

Production years

2001-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Orchard/Vineyard tractorReference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Four-post ROPS. Cab optional with air-conditioning.Reference

Variants

PJ55utilityReference

PJN55orchardReference

PJV55vineyardReference

Engine

3.0L 3-cyl dieselReference

Fuel tank60.0 LReference

Engine41.0 kWReference

dieselReference

3-cylinderReference

air-cooledReference

Displacement3.0 LReference

EmissionsTier IReference

Power41.0 kWReference

Rated RPM2350Reference

Torque194.0 NmReference

Torque RPM1400Reference

Starter typeelectricReference

Transmission

12-speed synchromeshReference

24-speedReference

24-speed two-speed power shiftReference

TypesynchromeshReference

Gears12 forward and reverseReference

Gears24 forward and reverseReference

Typetwo-speed power shiftReference

PTO & Hydraulics

Valves4Reference

Pump flow39.4 lpmReference

Pump flow64.3 lpmReference

Steering flow19.7 lpmReference

Rear TypeIReference

Controltop-link draft sensingReference

Rear lift (at ends)2399 kgReference

Rear PTOindependentReference

Dimensions

2WD Wheelbase198 cmReference

4WD Wheelbase194 cmReference

Weight4806 to 5181 poundsReference

Rear tire360/70R24Reference

Ag rear360/70R24Reference

Length372 cmReference

2WD Width106 cmReference

4WD Width109 cmReference

Height (ROPS)224 cmReference

Height (cab)210 cmReference

4WD Cab Weight2350 kgReference

4WD ROPS Weight2180 kgReference

Ground clearance23 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
