Tractor · 2001Unverified
CaseIH PJV65
CaseIH PJV65 — PJ Series · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
4982 to 5357 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Four-post ROPS. Cab optional with air-conditioning.Reference
Variants
PJ65utilityReference
PJN65orchardReference
PJV65vineyardReference
Engine
4.0L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine48.5 kWReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.0 LReference
EmissionsTier IReference
Power48.5 kWReference
Rated RPM2350Reference
Torque250.0 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
12-speed synchromeshReference
24-speedReference
24-speed two-speed power shiftReference
TypesynchromeshReference
Gears12 forward and reverseReference
Gears24 forward and reverseReference
Typetwo-speed power shiftReference
PTO & Hydraulics
Valves4Reference
Pump flow39.4 lpmReference
Pump flow64.3 lpmReference
Steering flow19.7 lpmReference
Rear TypeIReference
Controltop-link draft sensingReference
Rear lift (at ends)2399 kgReference
Rear PTOindependentReference
Dimensions
2WD Wheelbase211 cmReference
4WD Wheelbase207 cmReference
Weight4982 to 5357 poundsReference
Rear tire360/70R24Reference
Ag rear360/70R24Reference
Length385 cmReference
2WD Width106 cmReference
4WD Width109 cmReference
Height (ROPS)237 cmReference
Height (cab)210 cmReference
4WD Cab Weight2429 kgReference
4WD ROPS Weight2259 kgReference
Ground clearance23 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
