Tractor · 2014Unverified
CaseIH Steiger 370 Rowtrac
CaseIH Steiger 370 Rowtrac — Steiger Rowtrac Series · 311 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
311 hp
Weight
19169 kg
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Articulated Crawler tractorReference
Built in Fargo, North Dakota, USAReference
Original price was $381,618 in 2015Reference
Drivearticulated crawlerReference
Final drivesplanetaryReference
Steeringhydraulic articulatedReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Surveyor Cab standard with air-conditioning.Reference
Variants
370wheeled tractorReference
370RTcrawler tractorReference
Engine
FPT 8.7L 6-cyl dieselReference
Fuel tank946.2 LReference
Exhaust fluid (DEF)159.0 LReference
Engine275.9 kWReference
FPTReference
variable-geometry turbocharger air-to-air aftercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.7 LReference
Bore/Stroke117 x 135 mmReference
EmissionsTier 4Reference
Emission controlselective catalytic reduction (SCR)Reference
Power275.9 kWReference
Maximum Power302.0 kWReference
Fuel systemelectronic high pressure common railReference
Cooling systemviscous fan driveReference
Rated RPM2000Reference
StarterelectricReference
Starter volts24Reference
Transmission
16-speed full power shiftReference
Typefull power shiftReference
Gears16 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)231.9 kWReference
Typepressure flow compensatedReference
Valves4 to 8Reference
Pump flow151.4 lpmReference
Pump flow208.2 lpmReference
Pump flow408.8 lpmReference
SCV flow132.5 lpmReference
Rear TypeIVNReference
Rear TypeIIIReference
Rear lift (at 24"/610mm)9072 kgReference
Rear Armsquick couplerReference
DrawbarCat. 4Reference
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase406 cmReference
Weight19169 kgReference
16-inch tracksReference
Length800 cmReference
Width243 cmReference
Width365 cmReference
Height (cab)384 cmReference
Max weight25787 kgReference
Front axleFlangeReference
Flange rear axleReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Batteries2Reference
Battery CCA1000Reference
Battery volts12Reference
CaseIH Steiger 370 Rowtrac Tracks
Width40 cmReference
Width45 cmReference
Width60 cmReference
Width76 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
