Tractor · 2008Unverified

CaseIH Steiger 385QT Quadtrac

Name: CaseIH Steiger 385QT Quadtrac
Brand: CaseIH

CaseIH Steiger 385QT Quadtrac · 339 hp. Reference specifications; pending source verification.

The CaseIH Steiger 385QT Quadtrac is a high-powered tractor model, rated at approximately 339 hp. It was manufactured from 2008 to 2010 and features a 6-cylinder turbocharged diesel liquid-cooled engine, paired with a tracked undercarriage and hydrostatic transmission. The tractor's operating weight is listed as 21840 kg, suitable for operations covering 1,500 acres or more.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

339 hp

Weight

21840 kg

Catalogue coverage

Variants represented

Richest spec table

52 rows

Recorded power

339 hp

Recorded weight

21840 kg

Transmissions

16-speed

Production years

2008-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIHReference

Built in Fargo, North Dakota, USAReference

Original price$318,177 (2010)Reference

Drivearticulated crawlerReference

Steeringhydrostatic powerReference

Integrated hydraulic wet disc brakesReference

Cab standard with heat and A/C, optional Luxury cabReference

Variants

385wheeled tractorReference

Engine

Iveco 12.9L 6-cyl dieselReference

Fuel tank1135.5 LReference

Engine287.1 kWReference

IvecoReference

turbocharged aftercooled dieselReference

6-cylinder 24-valveReference

liquid-cooledReference

Displacement12.9 LReference

Bore/Stroke135 x 150 mmReference

EmissionsTier 3Reference

Power287.1 kWReference

Maximum Power315.4 kWReference

Air cleanerdual paper elementsReference

Compression16.5:1Reference

Rated RPM2000Reference

Starter volts24Reference

Oil capacity31.0 LReference

Transmission

16-speedReference

TransmissionpowershiftReference

Gears16 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)252.8 kWReference

Valves4 to 5Reference

Valves4 to 9 (without 3-point hitch)Reference

Total flow151.4 lpmReference

Total flow208.2 lpmReference

Total flow340.7 lpmReference

Rear Type4NReference

Rear lift (at 24"/610mm)8948 kgReference

Rear PTOindependent optionalReference

Rear PTO Type1000Reference

Dimensions

Wheelbase391 cmReference

Weight21840 kgReference

30-inch tracksReference

Width111 cmReference

Shipping weight21840 kgReference

Max weight26308 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps175Reference

Batteries2Reference

Battery CCA1000Reference

Battery volts12Reference

CaseIH Steiger 385QT Tracks

Width76 cmReference

Width91 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
