Tractor · 2014Unverified

CaseIH Steiger 420

Name: CaseIH Steiger 420
Brand: CaseIH

CaseIH Steiger 420 — Steiger 4WD Series · 367 hp. Reference specifications; pending source verification.

The CaseIH Steiger 420 is a tractor with a rated output of 367 hp, categorising it among the higher-powered machines in its class. This model was manufactured from 2014 to 2023. It features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with a powershift transmission and four-wheel drive system. The listed weight is 18216 kg, making it suitable for large-scale operations of approximately 1,500 acres or more.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

367 hp

Max power

308.3 kW

Weight

18216 kg

Catalogue coverage

Variants represented

Richest spec table

86 rows

Recorded power

367 hp

Recorded weight

18216 kg

Transmissions

16-speed full power shift

Production years

2014-2023

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Four-wheel Drive (4WD) tractorReference

Built in Fargo, North Dakota, USAReference

Original price was $353,362 in 2015Reference

Four-wheel driveReference

Final drivesinboard planetaryReference

Steeringhydraulic articulatedReference

Brakeshydraulic wet discReference

Brakesengine brakeReference

Trailer brakeshydraulicReference

Surveyor Cab standard with air-conditioning.Reference

Variants

420wheeled tractorReference

420RTcrawler tractorReference

T9.480similar New Holland modelReference

Engine

FPT 12.9L 6-cyl dieselReference

Fuel tank1173.4 LReference

Exhaust fluid (DEF)159.0 LReference

Engine313.2 kWReference

Drawbar (tested)254.2 kWReference

FPTReference

wastegate turbocharged air-to-air aftercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement12.9 LReference

Bore/Stroke135 x 150 mmReference

EmissionsTier 4Reference

Emission controlselective catalytic reduction (SCR)Reference

Power313.2 kWReference

Maximum Power344.5 kWReference

Fuel systemelectronic high pressure common railReference

Cooling systemviscous fan driveReference

Rated RPM2100Reference

StarterelectricReference

Starter volts12Reference

Max power308.3 kWReference

Power at rated engine speed274.0 kWReference

Max power254.2 kWReference

Transmission

16-speed full power shiftReference

Typefull power shiftReference

Gears16 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)264.7 kWReference

PTO (tested)308.3 kWReference

Typepressure flow compensatedReference

Valves4 to 8Reference

Pump flow159.0 lpmReference

Pump flow215.7 lpmReference

Pump flow427.7 lpmReference

SCV flow132.5 lpmReference

Rear TypeIVNReference

Rear TypeIIIReference

Rear lift (at 24"/610mm)9072 kgReference

Rear Armsquick couplerReference

DrawbarCat. 4Reference

Rear PTOindependentReference

Rear PTO Type1000 (1.75)Reference

Engine RPM1000@1998 (early)Reference

Engine RPM1000@1811 (late)Reference

Power at rated PTO speed303.9 kWReference

Dimensions

Wheelbase375 cmReference

Weight18216 kgReference

Front tire710/70R42Reference

Rear tire710/70R42Reference

Ag front710/70R42Reference

Ag rear710/70R42Reference

Length739 cmReference

Width304 cmReference

Height (cab)384 cmReference

Max weight22453 kgReference

Front axle127 by 3048 mmReference

Bar rear axle127 by 3048 mmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps200Reference

Batteries2Reference

Battery CCA1000Reference

Battery volts12Reference

Test results

Diesel 16-speed 4WDSeptember 23 - October 1, 2014Link: OCED Tractor Test 2093 fileReference

PTO performanceReference

Fuel use85.2 l/hourReference

Fuel use81.4 l/hourReference

Fuel use82.1 l/hourReference

Drawbar performanceReference

Fuel use81.0 l/hourReference

Gear 4 used for power test.Reference

Max pull18943 kgReference

Gear 1 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
