Tractor · 2014Unverified

CaseIH Steiger 500 Rowtrac

Name: CaseIH Steiger 500 Rowtrac
Brand: CaseIH

CaseIH Steiger 500 Rowtrac — Steiger Rowtrac Series · 435 hp. Reference specifications; pending source verification.

The CaseIH Steiger 500 Rowtrac is a tractor with a rated power of 435 hp at the upper end of its class. It was produced from 2014 to 2023. Featuring a 6-cylinder turbocharged diesel liquid-cooled engine, the Steiger 500 Rowtrac is equipped with a tracked undercarriage and a powershift transmission. Its listed operating weight is 19,736 kg, and it is suited to operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

435 hp

Weight

19736 kg

Catalogue coverage

Variants represented

Richest spec table

71 rows

Recorded power

435 hp

Recorded weight

19736 kg

Transmissions

16-speed full power shift

Production years

2014-2023

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Articulated Crawler tractorReference

Built in Fargo, North Dakota, USAReference

Original price$460,779 (2014 )Reference

Original price$493 (487 2015 )Reference

Drivearticulated crawlerReference

Final drivesplanetaryReference

Steeringhydraulic articulatedReference

Brakeshydraulic wet discReference

Brakesengine brakeReference

Trailer brakeshydraulicReference

Surveyor Cab standard with air-conditioning.Reference

Variants

500wheeled tractorReference

500RTrow-crop crawlerReference

500QTcrawlerReference

Engine

FPT 12.9L 6-cyl dieselReference

Fuel tank946.2 LReference

Exhaust fluid (DEF)159.0 LReference

Engine372.9 kWReference

FPTReference

wastegate turbocharged air-to-air aftercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement12.9 LReference

Bore/Stroke135 x 150 mmReference

EmissionsTier 4Reference

Emission controlselective catalytic reduction (SCR)Reference

Power372.9 kWReference

Maximum Power410.1 kWReference

Fuel systemelectronic high pressure common railReference

Cooling systemviscous fan driveReference

Rated RPM2100Reference

StarterelectricReference

Starter volts24Reference

Transmission

16-speed full power shiftReference

Typefull power shiftReference

Gears16 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)324.4 kWReference

Typepressure flow compensatedReference

Valves4 to 8Reference

Pump flow159.0 lpmReference

Pump flow215.7 lpmReference

Pump flow427.7 lpmReference

SCV flow132.5 lpmReference

Rear TypeIVNReference

Rear TypeIIIReference

Rear lift (at 24"/610mm)9072 kgReference

Rear Armsquick couplerReference

DrawbarCat. 4Reference

Rear PTOindependentReference

Rear PTO Type1000Reference

Dimensions

Wheelbase406 cmReference

Weight19736 kgReference

16-inch tracksReference

Length800 cmReference

Width243 cmReference

Width365 cmReference

Height (cab)384 cmReference

Max weight25877 kgReference

Front axleFlangeReference

Flange rear axleReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps200Reference

Batteries2Reference

Battery CCA1000Reference

Battery volts12Reference

CaseIH Steiger 500 Rowtrac Tracks

Width40 cmReference

Width45 cmReference

Width60 cmReference

Width76 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
