Tractor · 2008Unverified
CaseIH Steiger 535QT Quadtrac
CaseIH Steiger 535QT Quadtrac — Farm/Agricultural tractor · 474 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
474 hp
Max power
398.7 kW
Weight
51000 to 52410 pounds
Hover a source tag to verify
Overview
ManufacturerCaseIHReference
Farm/Agricultural tractorReference
Built in Fargo, North Dakota, USAReference
Original price$375,121 (2010)Reference
Drivearticulated crawlerReference
Steeringhydrostatic powerReference
Integrated hydraulic wet disc brakesReference
Cab standard with heat and A/C, optional Luxury cabReference
Variants
535wheeled tractorReference
Engine
Cummins 14.9L 6-cyl dieselReference
Fuel tank1135.5 LReference
Engine398.9 kWReference
Drawbar (tested)303.0 kWReference
Cummins QSX15Reference
turbocharged dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement14.9 LReference
Bore/Stroke137 x 169 mmReference
EmissionsTier 3Reference
Power398.9 kWReference
Maximum Power439.2 kWReference
Air cleanerdual paper elementsReference
Compression17:1Reference
Rated RPM2100Reference
Starter volts24Reference
Max power398.7 kWReference
Power at rated engine speed353.2 kWReference
Max power303.0 kWReference
Transmission
16-speed full powershiftReference
Typefull powershiftReference
Gears16 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)352.7 kWReference
PTO (tested)398.7 kWReference
Valves4 to 5Reference
Valves4 to 9 (without 3-point hitch)Reference
Total flow159.0 lpmReference
Total flow215.7 lpmReference
Total flow355.8 lpmReference
Rear Type4NReference
Rear lift (at 24"/610mm)8948 kgReference
Rear PTOindependent optionalReference
Rear PTO Type1000Reference
Power at rated PTO speed374.1 kWReference
Dimensions
Wheelbase391 cmReference
Weight51000 to 52410 poundsReference
30-inch tracksReference
Width111 cmReference
Shipping23133 kgReference
Operating23773 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps200Reference
Batteries2Reference
Battery CCA1000Reference
Battery volts12Reference
CaseIH Steiger 535QT Tracks
Width76 cmReference
Width91 cmReference
Capacities
Max capacity26308 kgReference
Test results
Diesel 16-speed crawlerOctober 2 - 24, 2007Link: OCED Tractor Test 1911 fileReference
PTO performanceReference
Fuel use110.9 l/hourReference
Fuel use104.8 l/hourReference
Fuel use106.7 l/hourReference
Drawbar performanceReference
Fuel use102.6 l/hourReference
Gear 4 used for power test.Reference
Max pull22709 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
