Tractor · 2014Unverified

CaseIH Steiger 580

Name: CaseIH Steiger 580
Brand: CaseIH

CaseIH Steiger 580 — Steiger 4WD Series · 477 hp. Reference specifications; pending source verification.

The CaseIH Steiger 580 is a tractor with a rated power of 477 hp, positioning it at the powerful end of its class. Manufactured from 2014 to 2023, this tractor features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It has an operating weight of 21839 kg and is suited to operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

477 hp

Max power

402.9 kW

Weight

21839 kg

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

477 hp

Recorded weight

21839 kg

Transmissions

16-speed full power shift

Production years

2014-2023

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaseIH (a part of CNH)Reference

Four-wheel Drive (4WD) tractorReference

Built in Fargo, North Dakota, USAReference

Original price was $432,852 in 2015Reference

Four-wheel driveReference

Final drivesinboard planetaryReference

Steeringhydraulic articulatedReference

Brakeshydraulic wet discReference

Brakesengine brakeReference

Trailer brakeshydraulicReference

Surveyor Cab standard with air-conditioning.Reference

Variants

580wheeled tractorReference

580QTcrawler tractorReference

T9.645similar New Holland modelReference

Engine

FPT 12.9L 6-cyl dieselReference

Fuel tank1722.2 LReference

Exhaust fluid (DEF)249.8 LReference

Engine432.5 kWReference

Drawbar (tested)369.3 kWReference

FPTReference

two-stage turbocharged air-to-water intercooled air-to-air aftercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement12.9 LReference

Bore/Stroke135 x 150 mmReference

EmissionsTier 4Reference

Emission controlselective catalytic reduction (SCR)Reference

Power432.5 kWReference

Maximum Power475.8 kWReference

Fuel systemelectronic high pressure common railReference

Cooling systemhydraulically-driven fanReference

Rated RPM2100Reference

StarterelectricReference

Starter volts24Reference

Max power402.9 kWReference

Power at rated engine speed356.0 kWReference

Max power369.3 kWReference

Transmission

16-speed full power shiftReference

Typefull power shiftReference

Gears16 forward and 2 reverseReference

PTO & Hydraulics

PTO (claimed)352.7 kWReference

PTO (tested)402.9 kWReference

Typepressure flow compensatedReference

Valves4 to 8Reference

Pump flow159.0 lpmReference

Pump flow215.7 lpmReference

Pump flow427.7 lpmReference

SCV flow132.5 lpmReference

Rear TypeIVNReference

Rear lift (at 24"/610mm)8900 kgReference

Rear Armsquick couplerReference

DrawbarCat. 4Reference

DrawbarCat. 5Reference

Rear PTOindependentReference

Rear PTO Type1000 (1.75)Reference

Engine RPM1000@1811Reference

Power at rated PTO speed399.6 kWReference

Dimensions

Wheelbase391 cmReference

Weight21839 kgReference

Front tire710/70R42Reference

Rear tire710/70R42Reference

Ag front710/70R42Reference

Ag rear710/70R42Reference

Length762 cmReference

Width304 cmReference

Height (cab)396 cmReference

Max weight29937 kgReference

Front axle139 by 3048 mmReference

Bar rear axle139 by 3048 mmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps240Reference

Batteries2Reference

Battery CCA1000Reference

Battery volts12Reference

Test results

Diesel 16-speed 4WDOctober 6 - 11, 2016Link: OCED Tractor Test 2162 fileReference

PTO performanceReference

Fuel use105.6 l/hourReference

Fuel use98.4 l/hourReference

Fuel use103.3 l/hourReference

Drawbar performanceReference

Fuel use107.1 l/hourReference

Gear 5 used for power test.Reference

Max pull24754 kgReference

Gear 2 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
