Backhoe Loader · 1990Unverified
Caterpillar 416 II
Caterpillar 416 II — Backhoe loader tractor · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
13708 to 13973 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
Backhoe loader tractorReference
Drive4x2 2WDReference
Drive4X4 MFWD 4WDReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab optional with available air-conditioning.Reference
Engine
Perkins 3.9L 4-cyl dieselReference
Engine (gross)50.0 kWReference
Engine (net)46.2 kWReference
Perkins 4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power (net)46.2 kWReference
Power (gross)50.0 kWReference
Rated RPM2400Reference
Starter typeelectricReference
Oil capacity6.1 LReference
Coolant capacity18.1 LReference
Transmission
4-speed power shuttleReference
Typepower shuttleReference
Gears4 forward and reverseReference
Oil capacity8.6 LReference
Synchronized transmission with torque converter and power shuttle.Reference
Capacities
Fuel106.0 LReference
Front axle6.4 LReference
Rear axle15.9 LReference
PTO & Hydraulics
Hydraulic system79.1 LReference
Typeclosed centerReference
Capacity79.1 LReference
Pressure186.1 barReference
Total flow107.9 lpmReference
Dimensions
2WD Wheelbase210 cmReference
4WD Wheelbase205 cmReference
Weight13708 to 13973 poundsReference
Front tire11L-16Reference
Rear tire16.9-24Reference
2WD Industrial front11L-16Reference
4WD Industrial front10.5-20Reference
2WD Industrial rear16.9-24Reference
4WD Industrial rear19.5L-24Reference
Length683 cmReference
Width226 cmReference
2WD Operating weight6217 kgReference
4WD Operating weight6338 kgReference
Ground clearance29 cmReference
Steering wheel195 cmReference
Backhoe & Loader
Dig depth431 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps52Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Caterpillar 416 Backhoe
Backhoe typeCaterpillar 416 BackhoeReference
Transport height345 cmReference
Digging depth431 cmReference
2-Foot flat digging depth429 cmReference
Reach from pivot541 cmReference
Loading height337 cmReference
Bucket force4735 kgReference
Dipperstick force3327 kgReference
Caterpillar 416 Extendable Backhoe
Backhoe typeCaterpillar 416 Extendable BackhoeReference
Transport height345 cmReference
Digging depth (retracted stick)442 cmReference
Digging depth (extended stick)563 cmReference
2-Foot flat digging depth (retracted stick)439 cmReference
2-Foot flat digging depth (extended stick)560 cmReference
Reach from pivot (retracted stick)550 cmReference
Reach from pivot (extended stick)665 cmReference
Loading height (retracted stick)335 cmReference
Loading height (extended stick)404 cmReference
Bucket Rotation162°Reference
Swing Arc180°Reference
Bucket force (retracted stick)4653 kgReference
Bucket force (extended stick)4653 kgReference
Dipperstick force (retracted stick)3245 kgReference
Dipperstick force (extended stick)2224 kgReference
Caterpillar 416 II Height
344 cmReference
ROPS271 cmReference
Cab271 cmReference
Exhaust274 cmReference
Backhoe345 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
