Backhoe Loader · 1996Unverified

Caterpillar 416C

Name: Caterpillar 416C
Brand: Caterpillar

Caterpillar 416C — Backhoe loader tractor · 78 hp. Reference specifications; pending source verification.

The Caterpillar 416C is a backhoe loader with a rated power output of 78 horsepower, a mid-range figure for its class. It was manufactured from 1996 to 2001 and features a 4-cylinder diesel liquid-cooled engine paired with two-wheel drive. The operating weight of this model is listed as 6333 kilograms. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

78 hp

Weight

6333 kg

Catalogue coverage

Variants represented

Richest spec table

35 rows

Recorded power

78 hp

Recorded weight

6333 kg

Production years

1996-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaterpillarReference

Backhoe loader tractorReference

Two-wheel driveReference

Engine

Caterpillar 4.4L 4-cyl dieselReference

Fuel tank127.9 LReference

Engine (gross)58.2 kWReference

Engine55.9 kWReference

Caterpillar 3054Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power55.9 kWReference

Power (gross)58.2 kWReference

Starter typeelectricReference

PTO & Hydraulics

Total flow163.1 lpmReference

Dimensions

Wheelbase210 cmReference

Weight6333 kgReference

Length697 cmReference

Width235 cmReference

Height358 cmReference

Height (cab)277 cmReference

Operating weight6333 kgReference

Ground clearance29 cmReference

Backhoe & Loader

Dig depth174.0 to 218.3 inchesReference

Attachment overview

Front-end loaderReference

BackhoeReference

Caterpillar Backhoe

Backhoe typeCaterpillar BackhoeReference

Digging depth441 cmReference

Digging depth (extended stick)554 cmReference

Loading height348 cmReference

Loading height (extended stick)422 cmReference

Bucket force5308 kgReference

Bucket force (extended stick)5473 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
