Backhoe Loader · 2006Unverified

Caterpillar 420E

Name: Caterpillar 420E
Brand: Caterpillar

Caterpillar 420E — Backhoe loader tractor · 93 hp. Reference specifications; pending source verification.

The Caterpillar 420E is a backhoe loader rated at approximately 93 hp, a mid-range rating within its class. It was produced in 2006. The machine features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with mechanical front-wheel drive and a hydrostatic transmission. Its operating weight ranges from 15201 to 15490 pounds, suitable for operations spanning 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

93 hp

Weight

15201 to 15490 pounds

Catalogue coverage

Variants represented

Richest spec table

93 rows

Recorded power

93 hp

Transmissions

4-speed

Production years

2006-2006

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaterpillarReference

Backhoe loader tractorReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD optionalReference

Steeringhydrostatic powerReference

Wet disc brakesReference

ROPS canopy, optional cab with heat and A/CReference

Variants

420E ITIntegrated Toolcarrier loaderReference

Engine

Caterpillar 4.4L 4-cyl dieselReference

Engine (gross)69.0 kWReference

Engine66.4 kWReference

Caterpillar C4.4Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power66.4 kWReference

Power (gross)69.0 kWReference

Air cleanerdryReference

Rated RPM1800Reference

Torque408.2 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity6.5 LReference

Coolant capacity20.4 LReference

Transmission

4-speedReference

5-speedReference

TransmissionPower-ShuttleReference

Gears4 forward and reverseReference

Oil capacity18.5 LReference

TransmissionAuto-ShiftReference

Gears5 forward and 3 reverseReference

Oil capacity18.9 LReference

Capacities

Fuel170.3 LReference

Front axle9.5 LReference

Rear axle14.2 LReference

Max capacity11000 kgReference

PTO & Hydraulics

Hydraulic system95.0 LReference

Typeclosed center load sensingReference

Capacity95.0 LReference

Pressure249.0 barReference

Pressure228.0 barReference

Total flow162.8 lpmReference

Dimensions

Wheelbase220 cmReference

Weight15201 to 15490 poundsReference

Front tire12.5/80-18Reference

Rear tire19.5L-24Reference

Industrial front12.5/80-18Reference

Industrial rear19.5L-24Reference

Industrial front11L-16Reference

Industrial front340/80RReference

Industrial rear21L-24Reference

Industrial rear500/70R24Reference

Industrial rear19.5L-R24Reference

Length759 cmReference

Width243 cmReference

Ground clearance33 cmReference

Shipping6895 kgReference

Operating7026 kgReference

Backhoe & Loader

Dig depth172 to 215 inchesReference

Dump angle111 cmReference

Dump angle114 cmReference

Attachment overview

Front-end loaderReference

BackhoeReference

Caterpillar Backhoe

Backhoe typeCaterpillar BackhoeReference

Digging depth436 cmReference

Digging depth (retracted stick)439 cmReference

Digging depth (extended stick)546 cmReference

2-Foot flat digging depth431 cmReference

2-Foot flat digging depth (retracted stick)436 cmReference

2-Foot flat digging depth (extended stick)541 cmReference

8-Foot flat digging depth431 cmReference

8-Foot flat digging depth (retracted stick)436 cmReference

8-Foot flat digging depth (extended stick)541 cmReference

Reach from pivot673 cmReference

Reach from pivot (retracted stick)675 cmReference

Reach from pivot (extended stick)777 cmReference

Loading height363 cmReference

Loading height (retracted stick)358 cmReference

Loading height (extended stick)414 cmReference

Bucket force6293 kgReference

Bucket force (retracted stick)6288 kgReference

Bucket force (extended stick)6288 kgReference

Dipperstick force4382 kgReference

Dipperstick force (retracted stick)4361 kgReference

Dipperstick force (extended stick)3185 kgReference

Caterpillar 420E Height

358 cmReference

363 cmReference

Cab281 cmReference

Exhaust274 cmReference

Speeds

With 19.5x24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
