Backhoe Loader · 2006Unverified

Caterpillar 430E

Name: Caterpillar 430E
Brand: Caterpillar

Caterpillar 430E — Backhoe loader tractor · 101 hp. Reference specifications; pending source verification.

The Caterpillar 430E is a backhoe loader with a rated power of 101 hp, positioning it at the higher power end of its class. Designed in 2006, this model features a 4-cylinder turbocharged diesel liquid-cooled engine paired with a mechanical front-wheel drive system and hydrostatic transmission. Its operating weight ranges from 15708 to 16083 pounds. It is suitable for operations on land areas of 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

101 hp

Weight

15708 to 16083 pounds

Catalogue coverage

Variants represented

Richest spec table

80 rows

Recorded power

101 hp

Transmissions

4-speed

Production years

2006-2006

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaterpillarReference

Backhoe loader tractorReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD optionalReference

Steeringhydrostatic powerReference

Wet disc brakesReference

ROPS canopy, optional cab with heat and A/CReference

Variants

430E ITIntegrated Toolcarrier loaderReference

Engine

Caterpillar 4.4L 4-cyl dieselReference

Engine (gross)75.0 kWReference

Engine76.1 kWReference

Caterpillar C4.4Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power76.1 kWReference

Power (gross)75.0 kWReference

Rated RPM1800Reference

Torque473.2 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity6.5 LReference

Coolant capacity14.4 LReference

Transmission

4-speedReference

5-speedReference

TransmissionPower-ShuttleReference

Gears4 forward and reverseReference

Oil capacity18.5 LReference

TransmissionAuto-ShiftReference

Gears5 forward and 3 reverseReference

Oil capacity18.9 LReference

Capacities

Fuel170.3 LReference

Front axle6.5 LReference

Rear axle14.2 LReference

Max capacity11000 kgReference

PTO & Hydraulics

Hydraulic system95.0 LReference

Typeclosed center load sensingReference

Capacity95.0 LReference

Pressure249.0 barReference

Pressure228.0 barReference

Total flow162.8 lpmReference

Dimensions

Wheelbase220 cmReference

Weight15708 to 16083 poundsReference

Length736 cmReference

Width231 cmReference

Ground clearance33 cmReference

Shipping7125 kgReference

Operating7295 kgReference

Backhoe & Loader

Dig depth185 to 234 inchesReference

Dump angle111 cmReference

Dump angle114 cmReference

Attachment overview

Front-end loaderReference

BackhoeReference

Caterpillar Backhoe

Backhoe typeCaterpillar BackhoeReference

Digging depth469 cmReference

Digging depth (retracted stick)480 cmReference

Digging depth (extended stick)594 cmReference

2-Foot flat digging depth467 cmReference

2-Foot flat digging depth (retracted stick)477 cmReference

2-Foot flat digging depth (extended stick)591 cmReference

Reach from pivot604 cmReference

Reach from pivot (retracted stick)609 cmReference

Reach from pivot (extended stick)723 cmReference

Loading height396 cmReference

Loading height (retracted stick)391 cmReference

Loading height (extended stick)452 cmReference

Bucket force7208 kgReference

Bucket force (retracted stick)7112 kgReference

Bucket force (extended stick)7112 kgReference

Dipperstick force4508 kgReference

Dipperstick force (retracted stick)4413 kgReference

Dipperstick force (extended stick)3264 kgReference

Caterpillar 430E Height

358 cmReference

363 cmReference

Cab281 cmReference

Exhaust274 cmReference

Speeds

With 19.5x24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
