Industrial Tractor · 2007Unverified
Caterpillar D11T
Caterpillar D11T — Bulldozer · 935 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
935 hp
Weight
163200 to 230100 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
BulldozerReference
DrivecrawlerReference
Final drivestwo-stage planetaryReference
Cab standard with available air-conditioning.Reference
Engine
Caterpillar 32.1L 12-cyl dieselReference
Engine (gross)697.2 kWReference
Engine (net)633.8 kWReference
Caterpillar C32Reference
turbocharged aftercooled dieselReference
12-cylinderReference
liquid-cooled V-12Reference
Displacement32.1 LReference
Bore/Stroke145 x 162 mmReference
Power (net)633.8 kWReference
Power (gross)697.2 kWReference
Rated RPM1800Reference
StarterelectricReference
Starter volts24Reference
Oil capacity106.0 LReference
Coolant capacity238.5 LReference
Transmission
3-speed power shiftReference
Typepower shiftReference
Gears3 forward and reverseReference
Oil capacity344.5 LReference
Capacities
Fuel1608.6 LReference
Fuel1911.4 LReference
PTO & Hydraulics
Hydraulic system242.2 LReference
Typeopen centerReference
Capacity242.2 LReference
Pressure243.0 barReference
Pump flow620.7 lpmReference
Dimensions
Weight163200 to 230100 poundsReference
28-inch tracksReference
Length601 cmReference
11S dozer length824 cmReference
11U dozer length869 cmReference
Width360 cmReference
Shipping weight74027 kgReference
Operating weight104373 kgReference
Gauge289 cmReference
Caterpillar D11T attachments
bladeReference
Electrical
Charging systemalternatorReference
Charging amps100Reference
Batteries4Reference
Battery volts12Reference
Battery AH190Reference
Caterpillar D11T Tracks
Width71 cmReference
Length on ground444 cmReference
Area on ground6.3 m²Reference
Caterpillar D11T Height
Hood358 cmReference
ROPS467 cmReference
Cab439 cmReference
Exhaust459 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
