Tractor · 1987Unverified
Caterpillar D3C SA Special Application
Caterpillar D3C SA Special Application — Agricultural Crawler tractor · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
14284 to 14750 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Four-post ROPS.Reference
Engine
Caterpillar 5.2L 4-cyl dieselReference
Engine (gross)82.0 kWReference
Engine (net)75.3 kWReference
Drawbar (claimed)61.1 kWReference
Caterpillar 3204Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement5.2 LReference
Bore/Stroke114 x 127 mmReference
Power (net)75.3 kWReference
Power (gross)82.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 4 reverseReference
Dimensions
Weight14284 to 14750 poundsReference
14-inch tracksReference
Length370 cmReference
Width194 cmReference
Shipping weight6479 kgReference
Operating weight6690 kgReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Caterpillar D3C SA Tracks
Width35 cmReference
Length on ground205 cmReference
Area on ground1.5 m²Reference
Width50 cmReference
Area on ground2.1 m²Reference
Caterpillar D3C SA Height
Hood157 cmReference
ROPS271 cmReference
Exhaust274 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
