Tractor · 1984Unverified
Caterpillar D4E SA Special Application
Caterpillar D4E SA Special Application — Agricultural Crawler tractor · 97 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
97 hp
Weight
18450 to 19050 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
Agricultural Crawler tractorReference
Original price was $39,810 in 1985Reference
DrivecrawlerReference
Engine
Caterpillar 7.0L 4-cyl dieselReference
Engine (net)72.3 kWReference
Drawbar (claimed)55.2 kWReference
Caterpillar 3304Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement7.0 LReference
Bore/Stroke121 x 152 mmReference
Power (net)72.3 kWReference
Fuel systemdirect injectionReference
Rated RPM2000Reference
StarterelectricReference
Starter volts24Reference
Oil capacity18.9 LReference
Coolant capacity30.3 LReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and reverseReference
Capacities
Fuel238.5 LReference
PTO & Hydraulics
Hydraulic system22.7 LReference
Typeopen centerReference
Capacity22.7 LReference
Pressure82.7 barReference
Pump flow81.8 lpmReference
Dimensions
Weight18450 to 19050 poundsReference
16-inch tracksReference
Length335 cmReference
Shipping weight8368 kgReference
Operating weight8641 kgReference
Gauge152 cmReference
Steering wheel193 cmReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Caterpillar D4E SA Tracks
Width40 cmReference
Length on ground182 cmReference
Area on ground1.5 m²Reference
Caterpillar D4E SA Height
ROPS269 cmReference
Exhaust287 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
