Industrial Tractor · 2008Unverified
Caterpillar D4K
Caterpillar D4K — Model year 2008-20122012-2020 · 92 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
92 hp
Weight
17961 to 18742 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
Industrial Crawler tractorReference
DrivecrawlerReference
Final drivesdouble-reduction outboard planetaryReference
Four-post ROPS. Cab available with air-conditioning.Reference
Engine
Caterpillar 4.4L 4-cyl dieselReference
Engine (gross)68.6 kWReference
Engine (net)62.6 kWReference
Caterpillar C4.4Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power (net)62.6 kWReference
Power (gross)68.6 kWReference
Rated RPM1900Reference
StarterelectricReference
Starter volts12Reference
Oil capacity11.0 LReference
Coolant capacity22.4 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Capacities
Fuel194.9 LReference
PTO & Hydraulics
Hydraulic system59.4 LReference
Capacity59.4 LReference
Pressure206.0 barReference
Pump flow73.4 lpmReference
Dimensions
Weight17961 to 18742 poundsReference
18-inch tracksReference
Length327 cmReference
XL dozer length427 cmReference
LGP dozer length426 cmReference
Width200 cmReference
Width235 cmReference
Height (cab)271 cmReference
Height (exhaust)276 cmReference
Operating weight8147 kgReference
Operating weight8501 kgReference
Gauge154 cmReference
Gauge172 cmReference
Caterpillar D4K attachments
bladeReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Caterpillar D4K Tracks
XL width45 cmReference
XL length on ground226 cmReference
XL area on ground2.1 m²Reference
XL ground pressure0.4 barReference
LGP width63 cmReference
LGP length on ground226 cmReference
LGP area on ground2.9 m²Reference
LGP ground pressure0.3 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
