Tractor · 1977Unverified
Caterpillar D5B SA Special Application
Caterpillar D5B SA Special Application — Agricultural Crawler tractor · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Weight
22900 to 23320 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
Agricultural Crawler tractorReference
Original price was $67,760 in 1985Reference
DrivecrawlerReference
Engine
Caterpillar 10.5L 6-cyl dieselReference
Engine (net)89.5 kWReference
Drawbar (claimed)67.1 kWReference
Caterpillar 3306Reference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement10.5 LReference
Bore/Stroke121 x 152 mmReference
Power (net)89.5 kWReference
Rated RPM1900Reference
StarterelectricReference
Starter volts24Reference
Oil capacity27.4 LReference
Coolant capacity34.1 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 4 reverseReference
Oil capacity76.7 LReference
Capacities
Fuel280.1 LReference
PTO & Hydraulics
Hydraulic system22.7 LReference
Typeopen centerReference
Capacity22.7 LReference
Pressure137.9 barReference
Pump flow87.1 lpmReference
Dimensions
Weight22900 to 23320 poundsReference
18-inch tracksReference
Length388 cmReference
Width234 cmReference
Shipping weight10387 kgReference
Operating weight10577 kgReference
Gauge187 cmReference
Steering wheel193 cmReference
Electrical
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Caterpillar D5B SA Tracks
Width45 cmReference
Length on ground217 cmReference
Area on ground2.0 m²Reference
Caterpillar D5B SA Height
Hood175 cmReference
ROPS276 cmReference
Exhaust299 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
