Industrial Tractor · 1996Unverified

Caterpillar D5M

Name: Caterpillar D5M
Brand: Caterpillar

Caterpillar D5M — Bulldozer · 121 hp. Reference specifications; pending source verification.

The Caterpillar D5M is a mid-range industrial tractor model, rated at approximately 121 horsepower. Manufactured from 1996 to 2002, the D5M is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, paired with a tracked undercarriage featuring a powershift transmission. Its operating weight is listed at 11,702 kg, and it is suitable for operations spanning 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

121 hp

Weight

11702 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

121 hp

Recorded weight

11702 kg

Transmissions

3-speed power shift

Production years

1996-2002

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCaterpillarReference

BulldozerReference

DrivecrawlerReference

Final drivessingle-reduction planetaryReference

Two-post ROPS. Cab available with air-conditioning.Reference

Engine

Caterpillar 6.6L 6-cyl dieselReference

Engine (gross)90.2 kWReference

Engine (net)82.0 kWReference

Caterpillar 3116TReference

turbocharged dieselReference

6-cylinderReference

liquid-cooled inlineReference

Displacement6.6 LReference

Bore/Stroke105 x 127 mmReference

Power (net)82.0 kWReference

Power (gross)90.2 kWReference

Fuel systemdirect injectionReference

Rated RPM2100Reference

StarterelectricReference

Starter volts24Reference

Oil capacity26.1 LReference

Coolant capacity45.4 LReference

Transmission

3-speed power shiftReference

Typepower shiftReference

Gears3 forward and reverseReference

Oil capacity104.9 LReference

Capacities

Fuel218.0 LReference

PTO & Hydraulics

Hydraulic system67.0 LReference

Typeload sensingReference

Capacity67.0 LReference

Pressure206.8 barReference

Pump flow94.6 lpmReference

Dimensions

Weight11702 kgReference

22-inch tracksReference

Length355 cmReference

LGP Length373 cmReference

5VPAT dozer length454 cmReference

Width233 cmReference

LGP Width276 cmReference

Height (ROPS)299 cmReference

Height (exhaust)307 cmReference

Operating weight11702 kgReference

PA55 winch1276 kgReference

Ripper757 kgReference

Gauge177 cmReference

LGP Gauge200 cmReference

Caterpillar D5M attachments

bladeReference

Electrical

Charging systemalternatorReference

Charging amps70Reference

Batteries2Reference

Battery CCA750Reference

Battery volts12Reference

Battery AH100Reference

Caterpillar D5M Tracks

Width55 cmReference

Length on ground238 cmReference

Area on ground2.7 m²Reference

Ground pressure0.4 barReference

LGP width76 cmReference

LGP length on ground261 cmReference

LGP area on ground4.0 m²Reference

LGP ground pressure0.3 barReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
