Industrial Tractor · 1995Unverified
Caterpillar D6R
Caterpillar D6R — Model year 1995-20012002-20042005-2006 · 179 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
179 hp
Weight
32600 to 45600 pounds
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
BulldozerReference
DrivecrawlerReference
Final drivessingle-reduction planetaryReference
Four-post ROPS. Cab available with air-conditioning.Reference
Engine
Caterpillar 10.5L 6-cyl dieselReference
Engine (gross)133.5 kWReference
Engine (net)123.0 kWReference
Caterpillar 3306Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
The D6R was rated a 175 net HP with XL and XR undercarriage. The D6R LGP was rated at 185 net HP.Reference
Displacement10.5 LReference
Bore/Stroke121 x 152 mmReference
Power (net)123.0 kWReference
Power (gross)133.5 kWReference
Fuel systemdirect injectionReference
Rated RPM1900Reference
StarterelectricReference
Starter volts24Reference
Oil capacity27.6 LReference
Coolant capacity73.8 LReference
Transmission
3-speed power shiftReference
Typepower shiftReference
Gears3 forward and reverseReference
Oil capacity155.2 LReference
Capacities
Fuel382.3 LReference
PTO & Hydraulics
Hydraulic system75.7 LReference
Typeload sensing variable displacementReference
Capacity75.7 LReference
Pressure193.1 barReference
Pressure419.9 barReference
Pump flow190.0 lpmReference
Pump flow196.1 lpmReference
Dimensions
Weight32600 to 45600 poundsReference
22-inch tracksReference
Length406 cmReference
Length421 cmReference
Length449 cmReference
6S dozer length510 cmReference
6A dozer length521 cmReference
6SU dozer length529 cmReference
Width264 cmReference
Width342 cmReference
Height (ROPS)319 cmReference
Height (exhaust)309 cmReference
Gauge187 cmReference
Gauge223 cmReference
Shipping14787 kgReference
Operating18007 kgReference
Operating20684 kgReference
Caterpillar D6R attachments
bladeReference
Electrical
Charging systemalternatorReference
Charging amps70Reference
Batteries2Reference
Battery CCA750Reference
Battery volts12Reference
Battery AH100Reference
Caterpillar D6R Tracks
Standard width55 cmReference
Standard length on ground260 cmReference
Standard area on ground2.9 m²Reference
Standard ground pressure0.6 barReference
XL width55 cmReference
XL length on ground282 cmReference
XL area on ground3.2 m²Reference
XL ground pressure0.6 barReference
XR width55 cmReference
XR length on ground275 cmReference
XR area on ground3.1 m²Reference
XR ground pressure0.6 barReference
LGP width91 cmReference
LGP length on ground324 cmReference
LGP area on ground5.9 m²Reference
LGP ground pressure0.3 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
