Tractor · 1959Unverified
Caterpillar D7D
Caterpillar D7D — Agricultural Crawler tractor · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Max power
81.9 kW
Weight
11036 kg
Hover a source tag to verify
Overview
ManufacturerCaterpillarReference
Agricultural Crawler tractorReference
Built in Peoria, Illinois, USAReference
DrivecrawlerReference
Steeringmanual clutchesReference
Contracting band brakesReference
Open operator station.Reference
Engine
Caterpillar 13.6L 4-cyl dieselReference
Fuel tank246.0 LReference
Drawbar (tested)81.9 kWReference
CaterpillarReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement13.6 LReference
Bore/Stroke146 x 203 mmReference
Air cleaneroil bathReference
Compression15.7:1Reference
Rated RPM1200Reference
Starter type2-cylinder pony engineReference
Max power81.9 kWReference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 4 reverseReference
Clutchdry metallic discReference
Oil capacity37.9 LReference
Dimensions
Weight11036 kgReference
20-inch tracksReference
Length412 cmReference
Width246 cmReference
Height (hood)203 cmReference
Shipping weight11036 kgReference
Ground clearance39 cmReference
Clearance (drawbar)43 cmReference
Gauge187 cmReference
Caterpillar D7D Tracks
Width50 cmReference
Test results
Turbo diesel 5-speed crawlerAugust 3 - 11, 1959Link: Nebraska Tractor Test 710 fileReference
Drawbar performanceReference
Fuel use31.4 l/hourReference
Gear 2 used for power test.Reference
Max pull12825 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
