Tractor · Unverified

CBT 2500

Name: CBT 2500
Brand: CBT

CBT 2500 · 89 hp. Reference specifications; pending source verification.

The CBT 2500 is a tractor with an output of 89 hp, positioning it in the middle of its class in terms of power. It features a 6-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission and two-wheel drive. The tractor's listed weight is 4889 kg, and it is suitable for tasks covering areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

89 hp

Weight

4889 kg

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

89 hp

Recorded weight

4889 kg

Transmissions

6-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCBTReference

Built in BrazilReference

Two-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic shoe brakesReference

Open operator stationReference

Engine

Perkins 5.8L 6-cyl dieselReference

Perkins 6-358Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.8 LReference

Bore/Stroke104 x 114 mmReference

Air cleaneroil bathReference

Compression15:1Reference

Rated RPM2200Reference

Torque349.2 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity14.7 LReference

Coolant capacity22.0 LReference

Transmission

6-speedReference

Gears6 forward and 2 reverseReference

Clutchdry discReference

Oil capacity30.3 LReference

PTO & Hydraulics

PTO (claimed)66.1 kWReference

Hydraulic system56.8 LReference

Capacity56.8 LReference

Rear TypeIIReference

Rear lift (at 24"/610mm)1999 kgReference

Rear PTO Type543Reference

Capacities

Fuel152.9 LReference

Dimensions

Wheelbase216 cmReference

Weight4889 kgReference

Front tire9.00-16Reference

Rear tire18.4/15-34Reference

Ag front9.00-16Reference

Ag front10.00-16Reference

Ag rear18.4/15-34Reference

Ag rear23.1/18-26Reference

Length422 cmReference

Width258 cmReference

Height273 cmReference

Operating weight4889 kgReference

Ballasted weight6255 kgReference

Clearance (front axle)38 cmReference

Clearance (rear axle)76 cmReference

Clearance (drawbar)50 cmReference

Front tread169 to 210 cmReference

Rear tread169 to 210 cmReference

Electrical

Charging systemalternatorReference

Charging amps30Reference

Charging volts14Reference

Batteries2Reference

Battery volts6Reference

Battery AH150Reference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
