Tractor · Unverified
CBT 2500
CBT 2500 · 89 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
89 hp
Weight
4889 kg
Hover a source tag to verify
Overview
ManufacturerCBTReference
Built in BrazilReference
Two-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic shoe brakesReference
Open operator stationReference
Engine
Perkins 5.8L 6-cyl dieselReference
Perkins 6-358Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke104 x 114 mmReference
Air cleaneroil bathReference
Compression15:1Reference
Rated RPM2200Reference
Torque349.2 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity14.7 LReference
Coolant capacity22.0 LReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity30.3 LReference
PTO & Hydraulics
PTO (claimed)66.1 kWReference
Hydraulic system56.8 LReference
Capacity56.8 LReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1999 kgReference
Rear PTO Type543Reference
Capacities
Fuel152.9 LReference
Dimensions
Wheelbase216 cmReference
Weight4889 kgReference
Front tire9.00-16Reference
Rear tire18.4/15-34Reference
Ag front9.00-16Reference
Ag front10.00-16Reference
Ag rear18.4/15-34Reference
Ag rear23.1/18-26Reference
Length422 cmReference
Width258 cmReference
Height273 cmReference
Operating weight4889 kgReference
Ballasted weight6255 kgReference
Clearance (front axle)38 cmReference
Clearance (rear axle)76 cmReference
Clearance (drawbar)50 cmReference
Front tread169 to 210 cmReference
Rear tread169 to 210 cmReference
Electrical
Charging systemalternatorReference
Charging amps30Reference
Charging volts14Reference
Batteries2Reference
Battery volts6Reference
Battery AH150Reference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
