Tractor · Unverified

CBT 2600

Name: CBT 2600
Brand: CBT

CBT 2600 · 92 hp. Reference specifications; pending source verification.

The CBT 2600 is a tractor with a rating of 92 hp, placing it in the middle of its class for power output. It is equipped with a 6-cylinder diesel liquid-cooled engine, which powers a two-wheel drive system with a hydrostatic transmission. The tractor has a listed weight of 4957 kg and is designed for use on farm areas of approximately 200-800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

92 hp

Weight

4957 kg

Catalogue coverage

Variants represented

Richest spec table

57 rows

Recorded power

92 hp

Recorded weight

4957 kg

Transmissions

6-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerCBTReference

Built in BrazilReference

Two-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic shoe brakesReference

Open operator stationReference

Engine

Mercedes-Benz 5.7L 6-cyl dieselReference

Mercedes-Benz OM-352Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement5.7 LReference

Bore/Stroke97 x 128 mmReference

Air cleaneroil bathReference

Compression17:1Reference

Rated RPM2200Reference

Torque353.1 NmReference

Torque RPM1600Reference

Starter volts12Reference

Oil capacity16.5 LReference

Coolant capacity20.0 LReference

Transmission

6-speedReference

Gears6 forward and 2 reverseReference

Clutch13-inch dry discReference

Oil capacity30.3 LReference

PTO & Hydraulics

PTO (claimed)68.7 kWReference

Hydraulic system56.8 LReference

Capacity56.8 LReference

Rear TypeIIReference

Rear lift (at 24"/610mm)1999 kgReference

Rear PTO Type543Reference

Capacities

Fuel152.9 LReference

Dimensions

Wheelbase216 cmReference

Weight4957 kgReference

Front tire9.00-16Reference

Rear tire18.4/15-34Reference

Ag front9.00-16Reference

Ag front10.00-16Reference

Ag rear18.4/15-34Reference

Ag rear23.1/18-26Reference

Length439 cmReference

Width217 cmReference

Height264 cmReference

Operating weight4957 kgReference

Ballasted weight6373 kgReference

Clearance (front axle)38 cmReference

Clearance (rear axle)75 cmReference

Clearance (drawbar)50 cmReference

Front tread169 to 210 cmReference

Rear tread169 to 210 cmReference

Electrical

Charging systemalternatorReference

Charging amps30Reference

Charging volts14Reference

Batteries2Reference

Battery volts6Reference

Battery AH137Reference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
