Tractor · 2005Unverified
Century C29
Century C29 — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1651 kg
Hover a source tag to verify
Overview
DistributorCenturyReference
ManufacturerKukjeReference
Compact Utility tractorReference
Built in Yangsu-ri, South KoreaReference
Four-wheel driveReference
Differential lockfoot pedalReference
Steeringhydrostatic powerReference
Differential wet disc brakesReference
ROPS.Reference
Engine
Kukje 1.5L 3-cyl dieselReference
Engine21.6 kWReference
KukjeReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 88 mmReference
Power21.6 kWReference
Air cleanerdry elementReference
Compression21.2:1Reference
Rated RPM2600Reference
Starter volts12Reference
Coolant capacity9.3 LReference
Oil capacity6.1 LReference
Transmission
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Oil capacity35.0 LReference
Oil type[21o↔-40oC]Reference
10oF [-12oC]↑: JDM J20CReference
70o↔-40oF [21o↔-40oC]: JDM J20DReference
Four gears in three ranges with left-hand shuttle. Gear shift is synchronized with clutch. Tractor must be stopped to shift range and shuttle.Reference
PTO & Hydraulics
PTO (claimed)18.6 kWReference
Hydraulic system35.0 LReference
Typeopen centerReference
Capacity35.0 LReference
Valves1 to 3Reference
Pump flow33.7 lpmReference
Total flow50.0 lpmReference
Rear TypeIReference
Rear lift (at ends)1170 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/1000Reference
Capacities
Fuel40.1 LReference
Front axle7.0 LReference
Dimensions
Wheelbase165 cmReference
Weight1651 kgReference
Front tire7-16Reference
Rear tire12.4-24Reference
Ag front7-16Reference
Ag rear12.4-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Industrial front27x8.50-15Reference
Industrial rear15x19.5Reference
Industrial front10-16.5Reference
Industrial rear420/70-24Reference
Length304 cmReference
Width149 cmReference
Height241 cmReference
Ground clearance28 cmReference
Front tread119 cmReference
Rear tread114 to 149 cmReference
C29 Serial Numbers
Location:Rear of tractor below PTO.Reference
Electrical
GroundnegativeReference
Charging amps45Reference
Battery volts12Reference
Speeds
With 12.4-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
