Tractor · 2005Unverified
Century C38
Century C38 — Compact Utility tractor · 32 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
32 hp
Weight
1710 kg
Hover a source tag to verify
Overview
DistributorCenturyReference
ManufacturerKukjeReference
Compact Utility tractorReference
Built in Yangsu-ri, South KoreaReference
Four-wheel driveReference
Differential lockfoot pedalReference
Steeringhydrostatic powerReference
Differential wet disc brakesReference
ROPS.Reference
Engine
Kukje 1.8L 4-cyl dieselReference
Engine28.3 kWReference
KukjeReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke84 x 94 mmReference
Power28.3 kWReference
Air cleanerdry elementReference
Compression22.2:1Reference
Rated RPM2600Reference
Starter volts12Reference
Coolant capacity9.3 LReference
Oil capacity6.1 LReference
Transmission
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Oil capacity35.0 LReference
Oil type[21o↔-40oC]Reference
10oF [-12oC]↑: JDM J20CReference
70o↔-40oF [21o↔-40oC]: JDM J20DReference
Four gears in three ranges with left-hand shuttle. Gear shift is synchronized with clutch. Tractor must be stopped to shift range and shuttle.Reference
PTO & Hydraulics
PTO (claimed)23.9 kWReference
Hydraulic system35.0 LReference
Typeopen centerReference
Capacity35.0 LReference
Valves1 to 3Reference
Pump flow33.7 lpmReference
Total flow50.0 lpmReference
Rear TypeIReference
Rear lift (at ends)1170 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/1000Reference
Capacities
Fuel42.0 LReference
Front axle7.0 LReference
Dimensions
Wheelbase175 cmReference
Weight1710 kgReference
Front tire8-18Reference
Rear tire12.4-28Reference
Ag front8-18Reference
Ag rear12.4-28Reference
Lawn/turf front29x12.00-15Reference
Lawn/turf rear44x18.00-20Reference
Industrial front12-16.5Reference
Industrial rear17.5L-24Reference
Length314 cmReference
Width154 cmReference
Height243 cmReference
Ground clearance33 cmReference
Front tread127 cmReference
Rear tread114 to 149 cmReference
C38 Serial Numbers
Location:Rear of tractor below PTO.Reference
Electrical
GroundnegativeReference
Charging amps45Reference
Battery volts12Reference
Speeds
With 12.4-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
