Tractor · 2005Unverified

Century C47

Name: Century C47
Brand: Century

Century C47 — Compact Utility tractor · 40 hp. Reference specifications; pending source verification.

The Century C47 is a compact tractor model with a rated output of 40 hp. It was manufactured from 2005 to 2006 and features a 4-cylinder diesel liquid-cooled engine, which drives the four-wheel drive system via a 12-speed gearbox. Its listed weight is 1773 kg, making it suitable for tasks covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1773 kg

Catalogue coverage

Variants represented

Richest spec table

66 rows

Recorded power

40 hp

Recorded weight

1773 kg

Transmissions

12-speed partially synchronized

Production years

2005-2006

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorCenturyReference

ManufacturerKukjeReference

Compact Utility tractorReference

Built in Yangsu-ri, South KoreaReference

Four-wheel driveReference

Differential lockfoot pedalReference

Power steeringReference

Differential wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Kukje 2.3L 4-cyl dieselReference

Engine35.0 kWReference

KukjeReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.3 LReference

Bore/Stroke88 x 94 mmReference

Power35.0 kWReference

Air cleanerdry cartridgeReference

Compression21.3:1Reference

Rated RPM2600Reference

Starter volts12Reference

Coolant capacity9.3 LReference

Oil capacity6.6 LReference

Transmission

12-speed partially synchronizedReference

Typepartially synchronizedReference

Gears12 forward and reverseReference

Oil capacity35.0 LReference

Oil type[21o↔-40oC]Reference

10oF [-12oC]↑: JDM J20CReference

70o↔-40oF [21o↔-40oC]: JDM J20DReference

Four gears in three ranges with left-hand shuttle. Gear shift is synchronized with clutch. Tractor must be stopped to shift range and shuttle.Reference

PTO & Hydraulics

PTO (claimed)29.8 kWReference

Hydraulic system35.0 LReference

Typeopen centerReference

Capacity35.0 LReference

Valves1 to 3Reference

Pump flow33.7 lpmReference

Total flow50.0 lpmReference

Rear TypeIReference

Rear lift1170 kgReference

Rear PTOliveReference

Rear PTO Type540/1000Reference

Capacities

Fuel42.0 LReference

Front axle7.0 LReference

Dimensions

Wheelbase180 cmReference

Weight1773 kgReference

Front tire8-18Reference

Rear tire12.4-28Reference

Ag front8-18Reference

Ag rear12.4-28Reference

Lawn/turf front29x12.00-15Reference

Lawn/turf rear44x18.00-20Reference

Industrial front12-16.5Reference

Industrial rear17.5L-24Reference

Length314 cmReference

Width154 cmReference

Height243 cmReference

Ground clearance30 cmReference

Front tread127 cmReference

Rear tread114 to 149 cmReference

C47 Serial Numbers

Location:Below PTO on rear of tractor.Reference

Electrical

GroundnegativeReference

Charging amps45Reference

Battery volts12Reference

Speeds

With 12.4-28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
